- Page 1 Model: HD4XSTPMX Installation Guide Version 5.1...
-
Page 2: Safety Information
Safety Information: Electrical safety Use only the power supplies and the AC power cord that were included with your product. Use of other power supplies could damage the product or cause shock, or other hazards For Indoor Use only Avoid excessive humidity, or temperature extremes Do not place the product in any area where it may become wet. Unplug the power supplies and the AC power cord before cleaning, or removing any panels for servicing. When adding or removing devices to or from the product, disconnect all power cables from the existing product before you add a device. Operation safety Install the product in a well ventilated location. Keep ventilation opening free of obstructions. Don't block any ventilation openings on the unit. Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet. If you are unsure, please contact your authorized service center. ... -
Page 3: Table Of Contents
Contents Safety Information............2 Application Diagram............4 Features..................4 Matrix Front Panel Overview ..........5 Basic Front Panel Control ..........6 Matrix Back Panel Overview ..........7 Zone Receiver (RX) Overview ......... 8 Infrared Overview ............9 Remote Control Guide ........... 10 Ethernet cable recommendations ........ -
Page 4: Application Diagram
Application Diagram Features: 4 inputs, up to 8 outputs (Installer configurable). Non-blocking Matrix – view Any Source on Any Display. 3D, 1080P resolutions supported. Distributes HD video + Audio over single CAT6 cables up to 200ft (60m). -
Page 5: Matrix Front Panel Overview
Matrix Front Panel Overview: 1-Output Select 2-LCD Display 3- IR Receiver 4- Control and function select Item Description Output Select Press to switch inputs for output Zones LCD Display IR Receiver IR receiver Control and function select... -
Page 6: Basic Front Panel Control
Basic Front Panel Control: Description LCD Display Turn On Turns On the matrix from the front panel Press fn+ power matrix on/off P o w e r O N ... -
Page 7: Matrix Back Panel Overview
Matrix Back Panel Overview: Item Description Power 48v (PoE) provides power to Octava PoE compatible Zone Receiver (Rx) units Power 9v (Matrix) provides power to Octava Matrix Wired IR input connect Octava supplied IR Receiver Extension cable ( optional) for hidden cabinet installs requiring line of sight for IR control. -
Page 8: Zone Receiver (Rx) Overview
Zone Receiver (RX) Overview: A Zone Rx unit is positioned close to your display device and connected to the Octava Matrix with a Twisted Pair (CAT6) cable. An Octava compatible Zone receiver must be used with the HD4xSTPMX Matrix. Compatible Zone Receiver: HD70STP-RX The HD70STP-RX Zone Receiver uses Power over Ethernet, PoE and is directly powered by the HD4xSTPMX over the CAT6 cable. -
Page 9: Infrared Overview
Infrared Overview: IR can be routed from any of the 8 connected Zones back to control: 1) the Matrix and 2) the connected Source devices. The Matrix also allows IR Routing + IR Broadcast for maximum utility. Routed IR: The IR Out 1-4 are "routed" for optimum IR control. For example, If Zone H is switched to HDMI Input 4. -
Page 10: Remote Control Guide
Remote Control Guide: The Master Remote (Type D) can fully control the matrix from any zone or directly in front of matrix Turn On Standby/Off Matrix Zone Control Master Remote (Type D) Example: Press C3-switches Output C to Input3 Reserved for Reserved for Customization Customization... -
Page 11: Ethernet Cable Recommendations
Note 2- Unshielded CAT5e and CAT6 cables can be used with your Octava system though they may result in limiting the maximum attainable distance depending on quality of cable. Cable Type... -
Page 12: Installation:basic Installation
Installation: Basic Installation Disconnect ALL Power cables from the MATRIX Disconnect ALL cables from the MATRIX / Zone Receivers Power OFF all HDTV/Displays/Audio Receivers Power OFF all Video Sources Power OFF Matrix Connect the 48VDC power supply to matrix Connect the 9VDC power supply to matrix... - Page 13 Continued on next page Connecting Output with CAT6 cables Connect CAT6 output A to Zone Receiver with CAT6 cable. Verify that the LED Indicator are illuminated as shown. Pwr LED = solid green Data LED = solid yellow Connect HDMI output to Display Repeat step 7 and 8 for all Zones Connecting HDMI sources /outputs and Audio Output Turn OFF the Power to the Matrix...
-
Page 14: Ir Installation
IR Installation I.R. Installation. Insert IR Receiver cable to the IR RX port of the Zone Receiver HD70STP-RX as shown. Insert IR Emitter cable to the IR Out ports of the Matrix HD70STPMX as shown. Connect a IR emitter cable to the IR Broadcast port if you need this feature. -
Page 15: Edid Configuration
EDID Configuration: The Octava Matrix can be configured to 5 EDID settings. It is recommended to keep the EDID in the default factory mode A. *Custom EDID mode can be downloaded via USB and stored as EDID mode E. Contact us for this feature. -
Page 16: Changing Edid Mode
Changing EDID mode: It is recommended to keep the EDID in the factory default MODE A. If necessary, you may set to different EDID mode by following these instructions. or view EDID Programming Instructions (video demo) at: www.octavainc.com/support and updates.html If you are unsure or need assistance, please contact us. -
Page 17: Scene Select
Scene Select: The HD4xSTPMX allows user to Quickly recall favorite Input/Output configurations. The default preset scenes are shown below. The scenes can be changed and programmed to meet your need. Scene IN/Out Configurations All outputs connected to Input 1 P r o g r a m O u t : A B C D E F G H ... -
Page 18: Scene Programming
S c e n e ‐ A : 1 2 3 4 1 2 3 4 panel buttons A-H to program the Scene for Use the Octava Remote Control to your preference. program the scenes Example: Programming Scene A Out A,E = 1 Out B.F= 2... -
Page 19: Powering Modes
Powering Modes: The following shows the status of matrix in ON / Standby / Off Mode Status Matrix = ON CAT6 Output (A-H) = ON Zone Receivers = ON Standby Matrix=Standby (low power mode) CAT6 Output (A-H) = ON, Zone Receivers=ON Matrix=Standby (low power mode) CAT6 Output (A-H) = OFF, Zone Receivers=OFF... -
Page 20: Sleep Mode
Sleep Mode: Sleep Mode feature is provided to optimize energy usage. The HD4XSTPMX is set with Sleep Mode = ON by default. Status Sleep Mode ON HD4xSTPMX enters Standby Mode after 12 hours. See page 18 *To exit Standby mode simply turn ON the matrix... -
Page 21: Usb Service Port
USB Service Port: The USB port is for service, EDID updates or customization requests Contact us for this feature or visit out support page for more info www.octavainc.com/support and updates.html... -
Page 22: Serial Control
Serial Control: The HD4XSTP can be controlled by serial commands. Serial commands can be sent to the HD4xSTP using the RS-232 port. Display Press Menu Button Goto Serial Control S e r i a l C o n t r o l P o r t ... -
Page 23: Serial Control Rs-232 Control Setup
Serial Control RS-232 Control Setup: The Matrix can be easily integrated with 3 Party control systems via RS232 control. The following shows the RS-232 pin out and control protocol for controlling the Matrix. RS-232 Port Pin 2 Receive Data Pin 3 Transmit Data Pin 5 Signal Ground... -
Page 24: Serial Commands- (Basic)
Serial Commands- (Basic): Controlling the Matrix via RS232 can be done by send a series of commands per the RS232 Command Table Basic controls Note: The commands are in HEX. No spaces between HEX codes. “0x” denotes HEX. No need to enter “0x” HEX CODE Status 0x02... -
Page 25: Serial Commands- (Switching)
Serial Commands- (switching): Switching Commands Note: The commands are in HEX. No spaces between HEX codes. “0x” denotes HEX. No need to enter “0x” Output A Switching Commands HEX CODE Switch OUT A to Input port 1 0x02 0x32 0x31 0x31 0x03 Switch OUT A to Input port 2... - Page 26 Output G Switching Commands HEX CODE Switch OUT G to Input port 1 0x02 0x32 0x37 0x31 0x03 Switch OUT G to Input port 2 0x02 0x32 0x37 0x32 0x03 Switch OUT G to Input port 3 0x02 0x32 0x37 0x33 0x03 Switch OUT G to Input port 4...
-
Page 27: Serial Commands- (Status Response Code)
Serial Commands- (Status Response code): The HD4xSTPMX provides the status of the matrix via RS-232 via feedback. Feedback Status Response code: byte 1 --> STX 1111111111110N1NN ETX <-- byte 19 Description Response Code Byte 1 Start of Text ( header) -
Page 28: Serial Commands- (Forwarding)
The HD4xSTPMX can route commands from the RS-232 port to any connect Zones A-H for controlling the attached display * RS-232 Forwarding feature will only work when using the RS-232 port of the HD4xSTPMX. The LAN port does not support RS-232 Forwarding* Data Rate Zone... -
Page 29: Zone Receiver Serial Data (Rs-232) Port
Zone Receiver Serial Data (RS-232) Port: The HD4xSTPMX can route commands from the RS-232 port to any connect Zones A-H for controlling the attached display A 3 pin Phoenix connector is provided to connect with a RS-232 serial cable. Prepare your serial cable according to diagram below The following shows the cable configuration for sending serial commands from the Matrix to the RX ( display side). -
Page 30: Telnet Control
Search for the MAC address of the matrix . The assigned IP address will be indicated in the "device list" next to the MAC address. The MAC address of the matrix is labeled on back of unit Login octava Password octava... -
Page 31: Switching Commands
Basic Commands Telnet Command Turn ON LED backlight led=on Turn OFF LED backlight led=off Turn ON Power power=on Turn OFF Power power=off Sleep Mode ON sleep=on Sleep Mode OFF sleep=off Switching Commands Telnet Command Output A Switching Commands Switch OUT A to Input port 1 out:a=1 Switch OUT A to Input port 2 out:a=2... -
Page 32: Installing Transmitter Output Cards
Installing Transmitter Output cards : The HD4xSTPMX has configurable outputs allowing user to install additional cards. Step 4 Step1 Step 2 remove all cables from matrix Step 3 Step 5 Procedure Disconnect 48VDC and 9VDC power supply from the Matrix. - Page 33 Step 7 Step 6 Step 9 Step 8 Step 11 Step 10...
- Page 34 Procedure(cont'd) Remove the blank cover plate for the Output slot you wish to add. Out E shown. Install the TX card to the slot. Out E shown Attach the blank plates to the top cover with the thumb screws. Install top cover back on matrix Install and tighten the thumbscrews to TX modules Install the cover Screws (x13) with Philips screw driver Done...
-
Page 35: Warranty
If Octava's equipment fails because of defects (1) year from the date of receipt, Octava will at its option, A) repair or replace the equipment, or B) request return of equipment for refund of the price paid for the product provided that the equipment has not been subjected to mechanical, electrical or other abuse or modifications. -
Page 36: Specifications
IR control of the Matrix, x4 Sources (Routed) plus an AVR from Zone receivers. Wideband IR 20-60 KHz circuitry for maximum IR remote compatibility using Octava supplied IR cables. RS-232 Control the Matrix using serial commands or 3 party control software (HEX commands available).
