Octava UHD44MX-IP Install Manual page 18

EDIDPCM[x].
EDIDG[x].
EDIDMInit.
EDIDM[X]B[Y].
EDID/[x]/[y].
EDIDUpgrade[x
].
GetInPortEDID
[X]
%9979.
If the EDID data is available and the
audio part supports not only PCM
mode, then force-set it to support
PCM mode only. If the EDID data is
not available, then set it as initialized
EDID data.
Set the audio part of input port [x] to
PCM format in EDID database.
Get EDID data from output [x] and
display the output port number.
Restore the factory default EDID
data for each input.
Manually EDID switching. Enable
input [Y] to learn the EDID data of
output [X]. If the EDID data is not
available, then set it as initialized
EDID data.
Set the EDID data of input port [x] to
built-in EDID No. [y]. [y] = 0~11,
correspond to the 12 embedded
EDID data separately.
Upgrade EDID data via the RS232
port.
X represents the input port, and x=5
represents all input ports.
When the switcher receives the
command, it will show a message to
prompt you to send EDID file (.bin
file). Operations will be canceled
after 10 seconds.
Get the EDID data of input [x],
[x]=1~4
Get the DIP switcher status
EDIDPCM[x]
Hexadecimal EDID
data and carriage
return character
EDIDMInit.
EDIDM3B1
EDID/[x]/[y]
Please send the EDID
file
EDID Upgrade OK!
EDID RS232 GUI
CONTROL 1111
