Description
Model
HDMI Inputs
HDMI Outputs
Optical Audio Output
Version
IN/Out Connectors
HDCP
Display Selection
Single Link Range
Video Data Rate
Vertical Frequency Scan Rate
Dimension
DC adapter (included)
Rackmount capable
Remote control (IR)
For Questions and support:
Email :
info@octavainc.com
URL: www.octavainc.com
Copyright© 2010 Octava Inc. All rights reserved.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LL.C
All trademarks are the sole property of their respective companies
Specifications
HDMX42-V1.3
4
2
1
1.3
19 pin HDMI female type-A
HDCP
Remote, Manual, Smart Scan,
RS232
480 P, 720 I/P, 1080 I/P
6.75 Gbps
24 / 50 / 60 Hz
12.08 x 4.1 x 1.67 inch
(306.9 x 104.2 x 42.3mm)
5VDC, 2.5A
1RU, Rack mounts included
Infrared, discrete code.
Rev. B
V 1.3
Deep Color
Installation Guide
Advertisement
Table of Contents
Related Manuals for Octava HDMX42-V1.3
Summary of Contents for Octava HDMX42-V1.3
- Page 1 For Questions and support: Email : info@octavainc.com URL: www.octavainc.com Copyright© 2010 Octava Inc. All rights reserved. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LL.C All trademarks are the sole property of their respective companies...
-
Page 2: Table Of Contents
Table of contents 1. Application Diagram 2. Description 3. Features 4. Clear EYE 5. Smart Scan 6. Installation 7. Remote Control Guide 8. Configuring Smart Scan 9. Short Cuts 10. RS232 Controls 11. EDID Configuration 12. Changing EDID mode 13. 1 RU Rackmount 14. -
Page 3: Application Diagram
1 RU Rackmount : The Octava 4x2 HDMI Matrix Switch can be installed in a 1 RU rack by simply installing the rack mounts included. Application Diagram Disabling /Enabling Front Panel IR Remote Receiver: Description: To disable the front panel IR remote receiver-insert the plastic plug into the The Octava 4x2 HDMI Matrix Switch allows you display any 4 HD IR jack as shown. -
Page 4: Features
Matrix Smart Scan and turn ON Octava’s HDMI switch with Smart Scan saves you the hassle of fumbling with multiple remote controls. Simply power on the HDMI Re-power the source you want to view and the HDMI switch will automatically Matrix. - Page 5 LED Indicators Changing EDID mode: Front View Infrared Detector It is recommended to keep the EDID in the factory default MODE1. If necessary, you may set to different EDID mode by following these instructions. Step Action Notes Set the Smart Scan switch Infrared Manual Select to OFF...
-
Page 6: Remote Control Guide
2 CH PCM Basic Mode source. 1080I Turns ON/OFF the LED light. Turns ON/OFF the HDMI switch Other Not used Octava’s Remote control uses discrete code so can be easily integrated with most Universal Remote Controls such as Logitech’s Harmony. - Page 7 Basic Quick Start: Input Switch Controls Use the remote control to select the Display that you wish to control Input ASCII Function Selection followed by the Input (DVD, Settop) that you wish to watch. <STX>211<ETX> Select OUT A to Input port 1 <STX>212<ETX>...
-
Page 8: Configuring Smart Scan
Turn OFF LED Short Cuts: <STX>005<ETX> Turn ON Power <STX>006<ETX> Turn OFF Power The Octava 4x2 HDMI Matrix Switch offers several “short cuts” with the remote control for the most common scenarios. <STX>007<ETX> Turn ON Smart Scan <STX>008<ETX> Turn OFF Smart Scan...
