Octava UHD44MXA-IP Manual

4x4 hdmi 2.0 video audio matrix
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UHD44MXA-IP
4x4 HDMI 2.0 Video Audio Matrix

Advertisement

Table of Contents
loading

Related Manuals for Octava UHD44MXA-IP

Summary of Contents for Octava UHD44MXA-IP

  • Page 1 UHD44MXA-IP 4x4 HDMI 2.0 Video Audio Matrix...
  • Page 2 Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material ⚫ for possible future shipment Follow basic safety precautions to reduce the risk of fire, electrical shock and ⚫...

  • Page 4: Table Of Contents

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ...................... 1 2. Specification ....................... 2 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ......................5 4.
  • Page 5 UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 9.2 Basic Settings ....................22 9.3 RS232 Communication Commands ..............23 9.3.1 System Commands ................23 9.3.2 Control Management ................23 9.3.3 Query Commands ................. 24 9.3.4 Lock/unlock Commands ................ 27 9.3.5 Audio Commands .................. 27 9.3.6 HDCP Compliance ................

  • Page 6: Product Introduction

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 1. Product Introduction The UHD44MXA-IP is a professional 4x4 HDMI 2.0 Matrix Switcher with Audio Matrix. It includes 4 HDMI inputs, 4 HDMI outputs and the last two outputs with down-scaling function, which is designed for switching two HDMI2.0 and HDCP2.3 compliant signals.

  • Page 7: Specification

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 2. Specification Video Video Input (4) HDMI Video Input Connector (4) Type-A female HDMI Up to 4K@60Hz 4:4:4 Video input Video Resolution Video Output (4) HDMI Video Output Connector (4) Type-A female HDMI,...
  • Page 8 UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix < 0.05 dB, 1 kHz sine at 0 dBFS level (or max level before L-R Level deviation clipping) Frequency Response < ± 0.5dB 20Hz - 20KHz Deviation Output Load Capability 1k ohm and higher (supports 10x paralleled 10k ohm loads)

  • Page 9: Panel Description

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 3. Panel Description 3.1 Front Panel UHD44MXA-IP | Video Audio Matrix Name Description Illuminates green when device powered on; ⚫ Power Indicator ① Turns red in standby mode. ⚫ Built-in IR sensor, receives IR signal sent from IR sensor ②...

  • Page 10: Rear Panel

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 3.2 Rear Panel Name Description HDMI input ports, 4 in total, connects with HDMI INPUTS ① sources. HDMI: 4 in total, connects with HDMI displays. The OUTPUTS ② latter four HDMI ports have down-scaling function.

  • Page 11: Video Resolution Down-Scaling

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 4. Video Resolution Down-scaling The product supports video resolution down-scaling, the 4K input can be automatically downscaled to 1080p output for compatibility with 1080p display. Input Output Resolutio Color Refresh Downscale 1080p Specs...

  • Page 12: System Connection

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 5. System Connection 5.1 Usage Precaution Make sure all components and accessories included before installation. ⚫ System should be installed in a clean environment with proper temperature and ⚫ humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ⚫...

  • Page 13: Panel Control

    4x4 HDMI2.0 Matrix with Audio Matrix 6. Panel Control 6.1 I/O connection switching The front panel features four input selection buttons and four output selection buttons for switching I/O connection. To convert 1 input to 1 output: Example: Input 1 to Output 3 →...

  • Page 14: Clear Button

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix control. 6.5 CLEAR Button Please press the CLEAR button if want to withdraw an operation before the ENTER button comes into effect, meanwhile, the matrix will return to the previous status. www.octavainc.com info@octavainc.com...

  • Page 15: Ir Remote Control

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 7. IR Remote Control The Matrix Switcher features a built-in IR receiver to receive IR signal from IR remote to enable IR control. If the external IR receiver or other IR control device need to be used, the IR IN port on rear panel can be connected.

  • Page 16: Gui Control

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8. GUI Control The matrix can be controlled via TCP/IP. The default IP settings are: IP Address: 192.168.0.178 Subnet Mask: 255.255.255.0 Gateway: 192.168.0.1 Type 192.168.0.178 in the internet browser, it will enter the below log-in webpage:...

  • Page 17: Switching Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8.1 Switching Tab Use the 4x4 button grid on the page to set which inputs are directed to which outputs. For example, clicking the button on the Input 1 row and Output 1 column, directs input 1 to output 1.

  • Page 18: Audio Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8.2 Audio Tab Audio Setting • There are eight audio sources can be selected for four digital SPDIF output ports. Audio Output Audio Sources Ports Input Breakout Output Breakout SPDIF 1 & Analog 1...

  • Page 19: Configuration Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix Audio Volume • Four pairs analog L/R audio to control their outputs volume. 8.3 Configuration Tab EDID Copy www.octavainc.com info@octavainc.com 770-825-0388...
  • Page 20 UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix Copy the EDID of the selected output device to one or more input source device. ⚫ EDID Setting Select the compatible built-in EDID for the selected input source. ⚫ Upload user-defined EDID by the below steps: ⚫...

  • Page 21: Cec Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8.4 CEC Tab If the input source devices, output display devices support CEC, they can be controlled via the following CEC interface. Input Source Device Control Select one input source device to be controlled, and then press function buttons.
  • Page 22 UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix Output Display Device Control Select one output device to be controlled, and then press function buttons. ⚫ Note: It cannot control two or more output devices simultaneously. www.octavainc.com info@octavainc.com 770-825-0388...

  • Page 23: Rs232 Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8.5 RS232 Tab ASCII or HEX command format can be selected. ⚫ Baud Rate: Supports 2400, 4800, 9600, 19200, 38400, 57600 or 115200. ⚫ Command Ending: NULL, CR, LF or CR+LF can be chosen.

  • Page 24: Interface Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8.6 Interface Tab Modify the title bar label. ⚫ Modify the button labels. ⚫ www.octavainc.com info@octavainc.com 770-825-0388...

  • Page 25: Network Tab

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix 8.7 Network Tab Static IP or Dynamic Host Configuration Protocol (DHCP). ⚫ Modify the static IP Address, Subnet Mask, and Gateway. ⚫ 8.8 Access Tab www.octavainc.com info@octavainc.com 770-825-0388...

  • Page 26: Gui Upgrade

    UHD44MXA-IP | 4x4 HDMI 2.0 Video Audio Matrix Modify the login password. ⚫ Lock or unlock the front panel buttons. ⚫ 8.9 GUI Upgrade Please visit at http://192.168.0.178:100 for GUI online upgrade. Type the username and password (the same as the GUI log-in setting, modified password will be available only after rebooting) to login the configuration interface.

  • Page 27: Rs232 Control

    Uninstallation: Delete all the control software files in corresponding file path. ⚫ 9.2 Basic Settings Firstly, connect UHD44MXA-IP with necessary input devices and output devices. Then, connect it with a PC installed RS232 control software. Double-click the software icon to run this software.

  • Page 28: Rs232 Communication Commands

    Function Feedback Example PowerON. Power on Power ON! PowerOFF. Power off Power OFF! /*Name. Query the name of matrix UHD44MXA-IP /*Type. Query the model of matrix HDMI Matrix V1.0.0 /^Version. Query the version of firmware CPLD:V1.0.0 RST. Factory Default! Factory Default! 9.3.2 Control Management...

  • Page 29: Query Commands

    4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example =00, it means both output 3 and 4 ports. Disable output devices down-scaling function. [xx]=00~02, HDMI OUT xx Down DS[xx]OFF. xx =01~02 is the corresponding Scale OFF! number of output 3 or 4 port, if the xx =00, it means both output 3 and 4 ports.
  • Page 30 4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example Set the baud Baudratexxxx/xx Set Local RS232 Baudrate Is rate of local xxx/xxxxxx. xxxx/xxxxx/xxxxxx! serial port GUI Or RS232 Query Status: 4x4 HDMI Matrix RD-MUH44A-H2 V1.0.0 Power ON! Front Panel UnLock! Local RS232 Baudrate Is 9600! GUI_IP:192.168.0.178! Output 01 Switch To In 03!
  • Page 31 4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example LINK N N N N Input 01 EDID From 06 Internal EDID! Input 02 EDID From User Define EDID! Input 03 EDID From 06 Internal EDID! Input 04 EDID From 06 Internal EDID! OUT 01 HDCP BYPASS! OUT 02 HDCP BYPASS! OUT 03 HDCP BYPASS!

  • Page 32: Lock/Unlock Commands

    4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example Query the Preset 01 Sta: preset Out 01 In 01! [xx]=01~09, PresetSta[xx]. Out 02 In 01! xx =01~09 is Out 03 In 01! the number of Out 04 In 01! preset Preset 01 Sta: Out 01 In 01!

  • Page 33: Hdcp Compliance

    4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example [yy]=01~08 yy=01~04, it means de- embedded audio from HDMI1- 4 input, if the yy=05~08, it means de-embedded audio from HDMI1-4 output. [xx]=00~04 xx=01~04 is the number of the Analog output port, if the xx=00, it means all Analog Analog Out 01 Volume 61! output ports.

  • Page 34: Edid Management

    4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example [xx] =00~04, OUT 02 HDCP MAT Display! xx =01~04 is the number of OUT 03 HDCP MAT output port, if the xx =00, it Display! means all output ports. OUT 04 HDCP MAT Display! Output HDCP follows the value and status of input source...
  • Page 35 4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example Note: EDID user-defined can be used once, if switch to another EDID or exit, it will not be saved. [xx]=U. ⚫ xx=U means user-defined for built-in EDID(It can be saved in machine for using at any time).
  • Page 36 4x4 HDMI2.0 Matrix with Audio Matrix Command Function Feedback Example yy=01~04 is the number of input port, if the yy=00, it means all input ports. Send serial data to local. [X]= 1--2400；2--4800；3--9600；4- -19200；5--38400；6--57600；7-- /+[X]/[yy]:xxx. 115200. xxx. [yy] means the output port that sent serial data, yy=01 means local output.

  • Page 37: Cec Control

    4x4 HDMI2.0 Matrix with Audio Matrix 9.3.8 CEC Control If the input sources, HDBaseT output devices and local HDMI output devices are supports CEC, they can be controlled by sending the following command instead of IR remote. CEC[I/O][AA][BB][CC][DD]. The “[I]” represents the input port. The “[O]” represents the output port. ⚫...
  • Page 38 4x4 HDMI2.0 Matrix with Audio Matrix CECI0304440A. CECI[AA][BB][CC]0A. Enter main menu. CEC Input 03 Send Success! CECI0204440D. CECI[AA][BB][CC]0D. Exit menu. CEC Input 02 Send Success! CECI0204446D. CECI[AA][BB][CC]6D. Power on. CEC Input 02 Send Success! CECI0204446C. CECI[AA][BB][CC]6C. Power off. CEC Input 02 Send Success! ✓...

  • Page 39: Firmware Upgrade

    8) After firmware upgrade, the switcher should be restored to factory default by sending command. 11. Panel Drawing INPUTS ENTER PRESET RECALL HOLD TO STORE UHD44MXA-IP | Video Audio Matrix OUTPUTS CLEAR 436.4 mm INPUTS OUTPUTS AUDIO MATRIX OUTPUTS CONTROL...
  • Page 40 4x4 HDMI2.0 Matrix with Audio Matrix www.octavainc.com info@octavainc.com 770-825-0388...

  • Page 41: Troubleshooting And Maintenance

    4x4 HDMI2.0 Matrix with Audio Matrix 12. Troubleshooting and Maintenance Problems Potential Causes Solutions The connecting cables may Check whether the cables not be connected correctly or are connected correctly and Color losing or no it may be broken. in working condition. video signal output Make sure the connection is Fail or loose connection.
  • Page 42 4x4 HDMI2.0 Matrix with Audio Matrix powered on EDID management Change for another HDMI The HDMI cable is broken at does not work cable which is in good the output end. normally working condition. Switch again. Manage the EDID data There is a blank The display does not support manually to make the...

  • Page 43: Customer Service

    4x4 HDMI2.0 Matrix with Audio Matrix 13. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
