5.3.2 Lock/unlock Commands

Command
/%Lock;
/%Unlock;
%9961.

5.3.3 Switching Commands

Command
[x]All.
All#.
All$.
[x]#.
[x]$.
[x]@.
All@.
[x1]V[x2].
Status[x].
Status.
%9971.
%9972.
%9975.
Function
Lock the front panel buttons.
Unlock the front panel buttons.
Query the system locking status.
Function
Transfer signals from the input
channel [x] to all output channels.
(x=1~4)
Transfer all input signals to the
corresponding output channels
respectively like 1->1, 2->2...
Switch off all the output channels.
Transfer signals from the input
channel [x] to the output channel [x].
(x=1~4)
Switch off the output channel [x].
(x=1~4)
Switch on the output channel [x].
(x=1~4)
Switch on all output channels.
Switch the input channel [x1] to one
or several output channels ([x2],
separate output channels with
comma). (x1/x2=1~4)
Query the I/O connection status of
output [x]. (x=1~4, y=1~4)
Query the input channel to the output
channels one by one.
Query the connection status of the
inputs.
Query the connection status of the
outputs.
Query the I/O connection status.
Feedback Example
System Locked!
System Unlock!
System Locked/
Unlock!
Feedback Example
01 To All.
All Through.
All Closed.
01 Through.
01 Closed.
02 Open.
All Open.
AV: 02-> 04
AV: Y-> X
(AV: 04-> 01)
AV:01->01
AV:01->02
AV:01->03
AV:01->04
In 01 02 03 04
Connect Y Y Y Y
Out 01 02 03 04
Connect Y Y Y Y
Out 01 02 03 04
