%9976.

5.3.4 Scene Commands

Command
Save[Y].
Recall[Y].
Clear[Y].

5.3.5 HDCP Compliance

Command
/%[Y]/[X]:[Z].
%0801.
%9973.
%9974.

5.3.6 EDID Configuration

The DIP switcher status should be set as 1111 to enable Software EDID management
mode: RS232 control or Web-based GUI control.
Command
EDIDH[x]B[y].
Query the output resolution.
Function
Save the present operation to the
preset command [Y], ranges from 1 to
10.
Recall the preset command [Y].
Clear the preset command [Y].
Function
HDCP management command.
Y=O is for output;
X=1~4 is the number of the port, if
the X=ALL, it means all ports;
Z is for HDCP compliant status, the
value may be 1 (HDCP compliant) or
0 (not HDCP compliant).
Auto HDCP management, activate
carrier native mode
Query the HDCP status of the input
signals.
Query the HDCP status of the output
signals.
Function
Input port [y] learns the EDID from
output port [x].
In 04 04 04 04
Resolution
Out 1 1920x1080P
Out 2 1920x1080P
Out 3 1920x1080P
Out 4 1920x1080P
Feedback Example
Save To F6
Recall From F2
Clear F8
Feedback Example
/%O/ALL:0.
%0801
In 01 02 03 04
HDCP Y N Y N
Out 01 02 03 04
HDCP Y N Y N
Feedback Example
EDIDH1B1
