Configuring Smart Scan The Smart Scan is disabled before shipment. It is recommended to leave Smart Scan disabled in most applications. To enable the Smart Scan 1) Set the Configuration switch #1 to the up position. 2) Re-power the matrix. To disable Smart Scan 1) Set the Configuration switch #1 to the down position.
Front View Display LED Indicators Infrared Detector Infrared Manual Select Jack Back View CAT5/6 output DC Power IR Transmitter (To RECEIVER) Input RS232 HDMI Input EDID & Smart Scan HDMI Output (To TV) Switch (To TV) Switch Number Name Smart Scan EDID EDID Programming/LOCK...
Front Panel Control: Source Selection: You may use the front panel buttons to select the sources connected to each display. For example, To Set display A to Input 2. Simply press and release the A display button until the LED shows 2.
Connecting Using CAT 5/6 outputs: Connect CAT5e -1 of the HDMI Matrix and Receiver with CAT5e/6 cable. Connect CAT5e -2 of the HDMI Matrix and Receiver with CAT5e/6 cable. Connect the I.R. Receiver cable (optional) to the I.R. of HDMI Ethernet Receiver unit.
Remote Control Guide: Pressing LED Pressing ON/OFF Turns on/off the Turns On/Off the Blue LED light. HDMI Matrix DisplayA-D Source1-4 Using the Remote: Use the remote control to select the Display that you wish to control followed by the Input (DVD, Settop) that you wish to watch. For example: -Pressing “C4”...
EDID Configuration: The Matrix can be configured to 4 EDID settings. It is recommended to keep the EDID in the default factory mode 1. To change the EDID settings, please see section “changing EDID settings” for programming instructions. Mode Video Audio Description Switch settings...
Changing EDID mode: It is recommended to keep the EDID in the factory default MODE1. If necessary, you may set to different EDID mode by following these instructions. Step Action Notes Set the Smart Scan switch to OFF Disconnect all sources and display from Matrix Set the Progam/Lock switch #4 to “program...
Page 11
Press the A button on the LED will count front panel. LED will from 000 to 100 count from 000 to 100 while while programming. programming. Wait. Programming is complete when LED indicates “1” Set to LOCK Position Connect all video sources and displays and turn ON Re-power the Matrix.
RS-232 Control Commands The Octava 4x4 HD - CAT 5/6 Matrix Switch can be easily integrated with 3 Party control systems via RS232 control. The following shows the control protocol for controlling the HDHC44MX. RS-232 protocol Baud Rate 9600 Data Bits...
Page 13
Switching Commands Note: The commands are in HEX. No spaces between HEX codes. Output A Switching Commands HEX CODE Select OUT A to Input port 1 0x02 0x32 0x31 0x31 0x03 Select OUT A to Input port 2 0x02 0x32 0x31 0x32 0x03...
1 RU Rackmount : The Octava 4x4 HD - CAT 5/6 Matrix Switch can be installed in a 1 RU rack by simply installing the rack mounts included. Disabling /Enabling Front Panel IR Remote Receiver: To disable the front panel IR remote receiver-insert the plastic plug into the IR jack as shown.
I.R. Remote Control over CAT 5/6: IR remote signals can be carried over the CAT 5/6 cables to control the 1) matrix and 2) video sources. 1) Connect the IR receiver cable to the CAT 6/HDMI receiver as shown above 2) Connect the IR transmitter cables to the matrix IR TX 1-4 as shown above.
If Octava's equipment fails because of defects (1) year from the date of receipt, Octava will at its option, A) repair or replace the equipment, or B) request return of equipment for refund of the price paid for the product provided that the equipment has not been subjected to mechanical, electrical or other abuse or modifications.
