Step1. Connect the TCP/IP port of the UHD44MX-IP to Ethernet port of PC with
twisted pair.
Step2. Set the PC's network segment to the same as the UHD44MX-IP. Do please
remember the PC's original network segment.
Step3. Set the UHD44MX-IP's network segment to the same as the router.
Step4. Set the PC's network segment to the original one.
Step5. Connect the UHD44MX-IP and PC(s) to the router. In the same LAN, each PC
is able to control the UHD44MX-IP asynchronously.
Then it's able to control the device via a TCP/IP communication software.

6.2 TCP/IP Communication Software Control

(Exampled by TCPUDP software)
1) Connect a computer with TCPUDP software to UHD44MX-IP. Open the TCPUDP
software (or any other TCP/IP communication software) and create a connection,
enter the IP address and port of UHD44MX-IP (default IP: 192.168.0.178,
port:4001):
Figure 7- 2 Connect to LAN
