Applications
Compensation of
the HX0030 probe
Probe overcompensated
Probe correctly
compensated
Probe under-compensated
Act on the screw on the Probix HX0030 probe to adjust the compensation.
For an optimum response, adjust the low-frequency compensation of the probe so
that the plateau of the signal is horizontal.
59
