f
IY-HUB2
Cellular Remote Monitoring & Control System
12V-48V DC
SKU: IY-HUB2-EU/IY-HUB2-G
Document Contents
1.
Technical Specifications
2.
Regulatory
2a. Health & Safety
3.
Installing your Device
3a. Installation Guidelines
3b. Installation Instructions
3c. Connection Guide
4. Wiring Diagram
Box Contents
1 x IY-HUB2 Unit
1 x Power Fuse Loom
1 x 4G / 2G Blade Antenna
1. Technical Specifications
Technical Specifications
Materials & IP Rating:
Size & Mounting
Connectivity:
Input Channels:
Expansion Channels:
Output Channel:
Operating Power & Fuse:
Configuration:
Power Draw @ 12VDC
Product Guide
5.
IY-HUB2 DATA
6.
7.
9.
6x Sensor Tails
1 x GPS Antenna - 2m
PC/ABS, A2 stainless fittings
110mm x 95mm x 35mm, 4x M4 bolt
2G, 4G CAT1 LTE EU bands (-EU) or 2G, 4G CAT1 LTE Global Bands (-G)
Battery supply voltage, 6 Analogue 0 - 70 VDC, 2 Temperature, 2 0-10V DC
2 VE (Value Expansion) Channels. VE-Direct and Custom Compatible
4 via digital interface - connected add on required
7 - 70 VDC, 1A
Remote configuration by Cloud Portal
15 min updates = 5mAh, 5 min updates = 7mAh, Live connection = 40mAh
9a. Logging into your Cloud
Account
9b. Adding Your Device
9c. Device Tariff and Billing
9d. Connecting to your device
Storage
1 x Instruction Manual
1 x Safety and User Guide
1
Advertisement
Related Manuals for Metrix Insylty IY-HUB2
Summary of Contents for Metrix Insylty IY-HUB2
-
Page 1: Table Of Contents
IY-HUB2 Product Guide Cellular Remote Monitoring & Control System 12V-48V DC SKU: IY-HUB2-EU/IY-HUB2-G Document Contents Technical Specifications IY-HUB2 DATA 9a. Logging into your Cloud Account 9b. Adding Your Device Regulatory Troubleshooting 9c. Device Tariff and Billing 2a. Health & Safety 6a. - Page 2 Requirements for Relevant Connectable Products) Regulations 2023 (“Security Requirements”). Signed : Robert Kettlety Managing Director - Metrix Advanced Technologies Ltd Date: 22th September 2023 2a. Health & Safety Working in the vicinity of batteries, engines, engine room equipment and on vehicles and other installations is potentially hazardous.
-
Page 3: Installing Your Device
● Do not try to open the device, contact Support immediately. ● Warranty* will be voided if you open the device, an internal detector senses this. ● Higher battery voltages are potentially lethal. In all cases, Insytly products are designed for nominal 12-48V DC systems. - Page 4 3b. Installation Instructions Find a mounting surface within 100CM of a positive and negative connection. 2. Screw the 4G LTE antenna into the 4G LTE connector, as per the connector guide shown below (port 1). The antenna should be no closer than 20CM of other antennas. 3.
-
Page 5: Wiring Diagram
-Inputs 5,6,7,8,9 are all rated for 0-72V DC -Input 10 is rated for 0-70V DC and provides boot wake up -Input 11,12 are rated for 0-10V DC and must not be exceeded -Input 13,14 are designed for external communications to VE-Direct or custom devices only. - Page 6 5. Data from the IY-HUB2 Device Output Relay Module - Relay Position Status Channel 1 (1/0) Channel 2 (1/0) Channel 3 (1/0) Channel 4 (1/0) Battery Supply Voltage Voltage (V) Average Voltage (V) Max Voltage (V) Minimum Voltage (V) 0-70V DC A1, A2, A3, A4, A5 (GREEN wire) - Analogue input, 0/1 or Runtime Voltage (V) Average Voltage (V) Max Voltage (V)
-
Page 7: Troubleshooting
Onboard Accelerometer Current X Average X Maximum X Minimum X Current Y Average Y Acceleration Acceleration Acceleration Acceleration Acceleration Acceleration (m/s^2) (m/s^2) (m/s^2) (m/s^2) (m/s^2) (m/s^2) Maximum Y Minimum Y Current Z Average Z Maximum Z Minimum Z Acceleration Acceleration Acceleration Acceleration Acceleration... -
Page 8: Remotely Configurable
7. Remotely configurable settings via 4G Cloud Interface - Please request cloud account access for this feature and to change the below. The section below is technical and used primarily for those who like to understand how our system functions. In your settings interface in the cloud platform, a simple click and set dashboard is available for all settings below. -
Page 9: Setup Disclaimer & Support
8. Setup Disclaimer & Support This part of the documentation is to provide guidance on what can be configured on the hardware device. All configurations are made on the cloud portal and via the 4G connectivity of the product. The IY-HUB2 is a self install product, for assistance please raise a ticket and we can put you in touch with a local installer. - Page 10 9b. Logging into your Cloud Account The following setup requires a Desktop Chrome/Edge browser login to app.Insytly.com To access your device, please create an account at app.insytly.com if this is your first device or log in to your existing account. Follow the on screen instruction when signing up.
-
Page 11: 9E. Accessing Remotely
9e. Accessing Remotely Configurable Hardware Settings To access the device hardware settings, navigate to your device, then settings, this will be a gear type icon or similar. Then click dvanced Settings/Remote Hardware Settings. Your cloud user account will need the correct access rights enabled if you re not the admin. 9f. -
Page 12: Warranty
EXCEED THE PURCHASE PRICE OF THE INSYTLY PRODUCTS DESCRIBED HERE IN. Metrix Advanced Technologies ltd reserves the right to revise and improve its products as it sees fit. This publication describes the state of this product at the time of its publication and may not reflect the product at all times in the future Installation of the product supplied with this manual constitutes full acceptance of these terms.
