Descriptions of the Control Panel Keys

(2) TIME/DIV
+ + ENTER
Password setting
(12) CURSOR
(11) FILE/GROUP
1
. SPAN/POSI/TRACE
The key allows SPAN, POSITION, and TRACE settings to be made independently
for each channel. When the key is pushed, the display mode changes in the
sequence shown below. Use the
and the and
MONITOR
SPAN
POSITION
TRACE
2
. TIME/DIV
Push the [TIME/DIV] key to change the time axis display range on the waveform
screen.
6
(4) QUIT
(ALARM CLEAR)
(10) REVIEW
keys to change the setting values.
Displays digital values (default).
Change the span settings (change the waveform amplitude).
Change the position settings (adjust the upper and lower values of the
waveform).
Change the trace settings (set the waveform display to On or Off).
* If the [QUIT] key is pushed when the GL240 is in the SPAN, POSITION, or
TRACE mode, the display returns to MONITOR mode.
(9) DISPLAY
and keys to select the channel,
Key Pointers
(1) SPAN/POSI/TRACE
(3) MENU
(5) DIRECTION KEYS
(6) ENTER
(7) FAST FORWARD
(KEY LOCK)
(8) START/STOP
(USB DRIVE MODE)
