Thank you for choosing Graphtec midi LOGGER GL240.
The Quick Start Guide is to assist with the basic operations.
Please refer to the USER'S MANUAL (PDF) in the CD-ROM for more
in-depth information.
Check the exterior of the unit to ensure that there are no cracks, defects, or
any other damages before use.
Accessories
• Quick Start Guide : 1
• AC cable/AC adapter : 1
Nomenclature .......................................................................... 2
Connection Procedures ........................................................... 3
Safety Guide for using GL240 .................................................. 5
Descriptions of the Control Panel Keys ................................... 6
Descriptions of the Menu Screens ........................................... 9
Measuring Procedure ............................................................ 10
1. Preparations : Hardware set up for recording .......................................... 10
2. Setup : Menu Operation .......................................................................... 11
3. Data record : How to Record .................................................................... 14
4. Data Replay : How to Replay Recorded Data ........................................ 15
Additional Features ................................................................ 16
Trigger Functions to Control Recording Start/Stop Operations .................. 16
Span, Position and Trace Functions to Adjust the Waveform Display ......... 18
Specifications ........................................................................ 19
Standard Specifications .............................................................................. 19
External Input/Output Functions .................................................................. 19
Specification of input section .................................................................. 20
Installation Guide ..................................................................
• Ferrite core: 1
Contents
• CD-ROM : 1
21
1
