12
4. Push the [MENU] key and open the "DATA" menu.
5. Set the sampling interval to "1s".
Move the cursor to "Sampling" and then select "1s".
6. Set the Data Recording Medium to "SD memory card".
Here, a sample folder "TEST" will be created in the internal memory (SDI),
and then set the recorded data to be placed inside the "TEST" folder.
(1) Move the cursor to the File Name parameter and then push the [ENTER]
key.
(2) The data save destination box shown in the following screen opens.
In the data saving destination box, set the SD1 as the Recording
Medium.
(3) Move into the folder by pushing the [ ] key and move the cursor to the
"Create New Folder" and then push the [ENTER] key. The Folder Name
Input menu will be displayed.
(4) A text input box is displayed. Create a folder named "TEST".
(1) In the text type select; delete; insert; confirm items, move the cursor
to the A using the
(2) The selected text is displayed.
In the text select, move the cursor to the text using the
keys and then push the [ENTER] key.
Input "TEST", move the cursor to [OK] , and then push the [ENTER] key
to enter your setting.
and keys.
Text input box
(1) Select the text type, delete,
insert, confirm
(2) Select the character
, , and
