Summary of Contents for Advantech ASMB-782G2-00A1E
- Page 1 User Manual ASMB-782 LGA 1155 Intel® Xeon® E3 V2 ATX Server Board with 2 PCIe x16 slots (x8 link), 2 PCIe x4, USB 3.0, PCIe Gen III, Quad LANs...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Whether your new Advantech equipment is destined for the labo- ratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known.
-
Page 4: Declaration Of Conformity
Declaration of Conformity This device complies with the requirements in part 15 of the FCC rules: Operation is subject to the following two conditions: This device may not cause harmful interference This device must accept any interference received, including interference that may cause undesired operation. - Page 5 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 6 Initial Inspection Before you begin installing your motherboard, please make sure that the following materials have been shipped: 1 ASMB-782 Startup Manual 1 Driver CD (user’s manual is included) 2 Serial ATA HDD data cables 2 Serial ATA HDD power cables ...
-
Page 7: Table Of Contents
Contents Chapter Hardware Configuration......1 Introduction ....................2 Features ....................2 Specifications .................... 3 1.3.1 System ..................3 1.3.2 Memory ..................3 1.3.3 Input/Output .................. 3 1.3.4 Graphics..................3 1.3.5 Ethernet LAN ................3 1.3.6 Industrial Features ................ 4 1.3.7 Mechanical and Environmental Specifications......4 Jumpers and Connectors ................ - Page 8 2.11.4 ATX Soft Power Switch (JFP1 pins 1 & 3)........21 2.11.5 Reset Connector (JFP1 pins 2 & 4) ..........21 2.12 8-pin Alarm Board Connector (VOLT1)........... 21 2.13 Case Open Connector (JFP1 pin 6 & 8) ..........22 2.14 Front Panel LAN Indicator Connector (LANLED1 and LANLED2)..
- Page 9 Figure 3.25PCI Express Configuration ........49 Figure 3.26PCI Express Configuration ........50 Figure 3.27USB Configuration............ 51 Figure 3.28PCH Azalia ............... 52 Figure 3.29LAN Configuration ............ 52 3.5.2 System Agent (SA) Configuration ..........53 Figure 3.30System Agent (SA) Configuration......53 Figure 3.31Graphics Configuration..........54 Figure 3.32LAN configuration screen .........
- Page 10 Table B.10:External Speaker Connector (JFP1) ......82 B.11 Reset Connector (JFP1) ................. 82 Table B.11:Reset Connector (JFP1)........... 82 B.12 HDD LED Connector (JFP1)..............82 Table B.12:HDD LED Connector (JFP1) ........82 B.13 ATX Soft Power Switch (JFP1) ............... 83 Table B.13:ATX Soft Power Switch (JFP1) ........ 83 B.14 Front panel SMBus connector (FP_SMB1)..........
-
Page 11: Chapter 1 Hardware Configuration
Chapter Hardware Configuration... -
Page 12: Introduction
These powerful I/O capabilities ensure even more reliable data storage capabilities and high-speed I/O peripheral connectivity. The ASMB-782 also adopts Advantech’s unique, patented Sleep Mode Control Cir- cuit for AT Power Mode. With all the excellent features and outstanding performance, the ASMB-782 is the ideal platform for today’s industrial applications. -
Page 13: Specifications
USB port: Supports up to 4 USB 3.0 ports with transmission up to 5Gbps and 10 USB 2.0 ports with transmission rates up to 480 Mbps. LPC: One LPC connector to support Advantech LPC modules, such as TPM module. ... -
Page 14: Industrial Features
1.3.6 Industrial Features Watchdog timer: Can generate system reset or NC. The watchdog timer is pro- grammable, with each unit equal to one second or one minute (255 levels). 1.3.7 Mechanical and Environmental Specifications Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU) ... - Page 15 Audio front panel header LPT1 Parallel port COM2 Serial port: RS-232 JFP1 Front panel header LPC1 Low pin count connector for Advantech TPM LPC modules LANLED1 LAN1/2 LED extension connector LANLED2 LAN3/4 LED extension connector VOLT1 Voltage Display PMBUS1 PMBUS connector to communicate with power supply...
-
Page 16: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations LAN1_USB12 PCIE6 SYSFAN4 LAN2_USB56 PCIE5 VGA_COM1 LAN34 PCIE7 PCI4 PCI3 KBMS1 PCIE2 KBMS2 PCI1 DVI1 JUSB_1 COM2 COM2 EATXPWR1 LPT1 ATX8P_P1 JFP2 GPIO1 PSON1 LANLED1 LANLED2 SNMP1 PMBUS1 LPC1 LPC1 DIMMA0 DIMMA0 DIMMA1 USB13 DIMMB0 BAT_CON1 DIMMB1... -
Page 17: Asmb-782 Block Diagram
ASMB-782 Block Diagram (ECC) DDR3 1066/1333/1600 One PCIe x 4 slot Channel A Intel LGA 1155 (ECC) DDR3 1066/1333/1600 Intel® Xeon® E3 / E3 v2 / 2nd and One PCIe x16 slot (x8 link) 3rd Core™ i3 / (ECC) DDR3 1066/1333/1600 Pentium processors One PCIe x16 slot (x8 link) Channel B... -
Page 18: Jumper Settings
Jumper Settings This section provides instructions on how to configure your motherboard by setting the jumpers. It also includes the motherboard default settings and your options for each jumper. 1.8.1 How to set jumpers You can configure your motherboard to match the needs of your application by set- ting the jumpers. -
Page 19: Table 1.5: Watchdog Timer Output (Jwdt1)
1.8.1.3 Watchdog timer output (JWDT1) The ASMB-782 contains a watchdog timer that will reset the CPU. This feature means the ASMB-782 will recover from a software failure or an EMI problem. The JWDT1 jumper settings control the outcome of what the computer will do in the event the watchdog timer is tripped. -
Page 20: Table 1.7: Usb Power Switch (Jusb_1, Jusb_2)
1.8.1.5 USB power switch (JUSB_1, JUSB_2) The ASMB-782 contains a jumper that can support USB/KBMS power source from +5Vsb or +5V. The default setting is 1-2 closed which is supporting USB stand-by power under S5. When the jumper is 2-3 closed, the USB/KBMS power source will be switched to +5V if you want to disable USB stand-by power under S5, and under 2-3 closed, it won't support S3 and S4 mode. -
Page 21: System Memory
System Memory ASMB-782 has four 240-pin memory sockets for DDR3 ECC/Non-ECC 1066/1333/ 1600 MHz memory modules with maximum capacity of 32GB (Maximum 8GB for each DIMM). Please note that both versions ASMB-782 do NOT support registered DIMMs (RDIMMs). 1.10 Memory Installation Procedures To install DIMMs, first make sure the two handles of the DIMM socket are in the “open”... -
Page 22: Processor Installation
1.12 Processor Installation The ASMB-782 is designed for LGA1155, Intel Xeon® E3 V2/Core™ i3 processor. 1.13 PCI Bus Routing Table PCI1 PCI3 PCI4 PCI slot INT AD16 AD21 AD22 ASMB-782 User Manual... -
Page 23: Chapter 2 Connecting Peripherals
Chapter Connecting Peripherals... -
Page 24: Introduction
Introduction You can access most of the connectors from the top of the board as it is being installed in the chassis. If you have a number of cards installed, you may need to par- tially remove a card to make all the connections. Parallel Port (LPT1) LPT1 The parallel port is normally used to connect the motherboard to a printer. -
Page 25: Usb Ports (Lan1_Usb12,Lan2_Usb56,Usb34, Usb78, Usb910,Usb1112, Usb13, Usb14)
USB Ports (LAN1_USB12,LAN2_USB56,USB34, USB78, USB910,USB1112, USB13, USB14) ASMB-782 provides up 14 USB ports. USB5~14 are USB 2.0 ports supporting trans- mission rates up to 480 Mbps, and USB1~4 are USB 3.0 ports supporting transmis- sion rate up to 5Gbps.These ports support Plug & Play and hot swapping for up to 127 external devices and are able to be disabled in BIOS menu. -
Page 26: Usb Power Switch
LAN 3/4 LED Indicator LAN Mode LAN Indicator 1 Gbps Link on LED1 Green on (Right) 100 Mbps Link on LED1 Orange on (Right) 10 Mbps Link on LED1 N/A (Right) Active LED2 Green flash (left) USB Power Switch JUSB_1 Jumper USB Ports JUSB_1... -
Page 27: Vga Connector (Vga1)
VGA Connector (VGA1) VGA_COM1 The ASMB-782 includes a VGA interface that can drive conventional CRT displays. Pin assignments of VGA1 are detailed in Appendix B. Serial Ports (COM1, COM2) VGA1_COM1 COM2 COM1 COM2 The ASMB-782 offers two serial ports (one on the rear panel and one onboard).These ports can connect to a serial mouse, printer or communications net- work. -
Page 28: Ps/2 Keyboard And Mouse Connector (Kbms1)
PS/2 Keyboard and Mouse Connector (KBMS1) KBMS1 Two 6-pin mini-DIN connectors (KBMS1) on the rear panel of the motherboard pro- vide PS/2 keyboard and mouse connections. External Keyboard & Mouse (KBMS2) KBMS2 There is also an extra onboard external keyboard and mouse connector on the moth- erboard. -
Page 29: Cpu Fan Connector (Cpufan1)
CPU Fan Connector (CPUFAN1) CPUFAN_SEL1 CPUFAN1 If a fan is used, this connector supports cooling fans that draw up to 500 mA (6 W). 2.10 System FAN Connector (SYSFAN1, SYSFAN2, SYSFAN3 and SYSFAN4) SYSFAN4 SYSFAN1 STYSFAN2 SYSFAN3 STYSFAN4 SYSFAN_SEL1 SYSFAN2 SYSFAN3 SYSFAN1 If a fan is used, this connector supports cooling fans that draw up to 1A (12W). -
Page 30: Front Panel Connectors (Jfp1)
2.11 Front Panel Connectors (JFP1) There are several external switches and LEDs to monitor and control the ASMB-782. JFP1 2.11.1 Power LED (JFP1) JFP1 pin9 and pin13 are for the power LED. Refer to Appendix B for detailed infor- mation on the pin assignments. If a PS/2 or ATX power supply is used, the system’s power LED status will be as indicated as follows. -
Page 31: Atx Soft Power Switch (Jfp1 Pins 1 & 3)
Many computer cases offer the convenience of a reset button. 2.12 8-pin Alarm Board Connector (VOLT1) VOLT1 VOLT1 connects to the alarm board of Advantech chassis. These alarm boards give warnings if a power supply or fan fails, if the chassis overheats. ASMB-782 User Manual... -
Page 32: Case Open Connector (Jfp1 Pin 6 & 8)
2.13 Case Open Connector (JFP1 pin 6 & 8) JFP1 JFP1 pin 6 & 8 are for chassis with a case open sensor. The warning message will show in post screen. 2.14 Front Panel LAN Indicator Connector (LANLED1 and LANLED2) Table 2.2: Front Panel LAN Indicator Connector Signal Signal... -
Page 33: Serial Ata Interface (Sata0~5)
LANLED2 LANLED1 2.15 Serial ATA Interface (SATA0~5) SATA3 SATA1 SATA4 SATA5 SATA2 SATA0 ASMB-782 features two high performance serial ATA III interfaces (up to 600 MB/s, blue connector) and four serial ATA II interfaces (up to 300 MB/s, black connector). Note! ASMB-782 on board SATA only supports Fedora 14 and 15 and SATA mode in BIOS should be set as AHCI mode. -
Page 34: Pci Slots (Pci 1, 3, 4)
2.16 PCI Slots (PCI 1, 3, 4) PCI1 PCI3 PCI4 The ASMB-782 provides three 32-bit / 33 MHz PCI slots. 2.17 PCIe x16 slots (x8 link) Expansion Slot (PCIE5 and PCIE6) PCIE5 PCIE6 The ASMB-782 provides two PCIe x16 slots (x8 link) for users to install add-on VGA cards when their applications require higher graphics performance than the CPU embedded graphics controller can provide, or high bandwidth demanded I/O card, such as frame grabber card, raid card and 10G LAN card. -
Page 35: Pcie X4 Expansion Slot (Pcie2 And Pcie7)
2.18 PCIe x4 Expansion Slot (PCIE2 and PCIE7) PCIE2 PCIE7 2.19 Auxiliary 8-pin power connector (ATX8P_P1) For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version). Do not forget to con- nect the 8-pin EATX12 V power plug;... -
Page 36: Spi Flash Connector(Spi_Cn1)
2.20 SPI Flash connector(SPI_CN1) SPI flash card pin header which can flash BIOS while ASMB-782 can not be power on and ensures platform integrity. SP1_CN1 2.21 Low Pin Count Connector (LPC1) LPC1 ASMB-782 User Manual... -
Page 37: Bios Operation
Chapter BIOS Operation... -
Page 38: Introduction
Introduction AMIBIOS has been integrated into myriad motherboards for decades. In the past, people often referred to the AMIBIOS setup menu as BIOS, BIOS setup or CMOS setup. With the AMIBIOS Setup program, you can modify BIOS settings and control the special features of your computer. -
Page 39: Main Menu
3.2.1 Main Menu Press <Del> at bootup to enter AMI BIOS CMOS Setup Utility, the Main Menu will appear on the screen. Use arrow keys to select among the items and press <Enter> to accept or enter the sub-menu. Figure 3.2 Main setup screen The Main BIOS setup screen has two main frames. -
Page 40: Advanced Bios Features Setup
Advanced BIOS Features Setup Select the Advanced tab from the ASMB-782 setup screen to enter the Advanced BIOS setup screen. You can select any of the items in the left frame of the screen, such as CPU configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>... -
Page 41: Pci Subsystem Settings
PCI Subsystem Settings Figure 3.4 PCI subsystem settings screen Above 4G Decoding Enable or disable 64bit capable devices to be decoded in above 4G address space when system supports 64 bit PCI decoding. PCI Latency Timer Value in units of PCI clocks for PCI device latency timer register. VGA Palette Snoop This item is designed to solve problems caused by some non-standard VGA cards. -
Page 42: Figure 3.5 Pci Express Setting
Figure 3.5 PCI Express Setting Link Training Retry This item is to allow user to define numbers of retry attempts software will take to retrain the link if previous training attempt was unsuccessful. Link Training Time out To define number of microseconds waiting for "Link Training", and the value range is from 10 to 1000 uS. -
Page 43: Acpi Settings
3.4.1 ACPI Settings Figure 3.6 ACPI Settings Enable ACPI Auto Configuration "Enable” or “disable" ACPI Auto Configuration. Power On By Modem Power on by modem can be supported by COM1 and COM2. Enable Hibernation "Enable” or “disable" Hibernation. ACPI Sleep State Specifies the ACPI sleep state when the system enters suspend. -
Page 44: Trusted Computing
3.4.2 Trusted Computing Figure 3.7 TPM Settings TPM Support “Enable” or “disable” TPM Support. You can purchase Advantech LPC TPM module to enable TPM function. P/N: PCA-TPM-00A1E ASMB-782 User Manual... -
Page 45: Cpu Configuration
3.4.3 CPU Configuration Figure 3.8 CPU Configuration Hyper-threading This item allows you to enable or disable Intel Hyper Threading technology. Active Processor Core Use this to select how many processor cores you want to activate when you are using a dual or quad core processor. Limit CPUID Maximum Setting this item to [Enable] allows legacy operating systems to boot even without support for CPUs with extended CPUID functions. -
Page 46: Sata Configuration
system. It does this by creating virtual machines, each running its own x86 operating system. 3.4.4 SATA Configuration Figure 3.9 SATA Configuration SATA Controller(s) This item is to enable or disable SATA devices. SATA Mode Selection It's able to set as IDE, AHCI, or RAID when SATA Controllers are enable. SATA Controller Speed To set the maximum speed of SATA controllers, and there are three modes, Gen1, Gen2, and Gen3. -
Page 47: Intel Txt(Lt) Configuration
Figure 3.10 Software Feature Mask Configuration OROM UI Delay When this item is enable, user is able to indicate the delay of the OROM UI Splash Screen in a normal status. 3.4.5 Intel TXT(LT) Configuration Figure 3.11 Intel Trusted Execution Technology Configuration ASMB-782 User Manual... -
Page 48: Amt Configuration
Intel Trusted Execution Technology Configuration To enable or disable Intel Trusted Execution Technology if SMX is enable, and VT-D support must also be enabled prior to TXT. 3.4.6 AMT Configuration Figure 3.12 AMT Configuration Intel AMT Enable or Disable Intel Active Management Technology BIOS Extension. BIOS Hotkey Pressed To enable or disable BIOS hotkey press. -
Page 49: Usb Configuration
USB Configure To enable or disable USB configure function. PET Progress Enable or disable PET event progress to receive PET events. AMT CIRA Timeout Allows users to define the timeout for MPS connection. 0 means using the default timeout value of 60 seconds. 255 means MEBX waits until a connection has been established successfully. -
Page 50: Super Io Configuration
Device reset time-out Allows you to select the USB device reset time-out value. [10,20,30,40 sec] Device power-up delay This item appears only when you set the Device power-up delay item to [manual]. 3.4.8 Super IO Configuration Figure 3.14 Super IO Configuration ASMB-782 User Manual... -
Page 51: Figure 3.15Serial Port 1 Configuration
Figure 3.15 Serial Port 1 Configuration Figure 3.16 Serial Port 2 Configuration ASMB-782 User Manual... -
Page 52: Figure 3.17Parallel Configuration
Figure 3.17 Parallel Configuration Serial Port 1 Configuration Serial Port “Enable” or “disable” Serial Port 1. Change Settings Select optimal settings for serial port 1. Serial Port 2 Configuration Serial Port “Enable” or “disable” Serial Port 2. Change Settings Select optimal settings for serial port 2. Device Mode Serial port 2 could be selected as "Standard serial port mode", "IrDA 1.0 (HP SIR) mode", or "ASKIR mode". -
Page 53: H/W Monitor
3.4.9 H/W Monitor Figure 3.18 PC Health Status CPU Temperature (PECI) CPU temperature shown here is CPU T-junction temperature via PECI. Case Open Warning Enable/Disable the chassis Intrusion monitoring function. When enabled and the case is opened, a warning message will show in post screen. CPU Warning Temperature Use this to set the CPU warning temperature threshold. -
Page 54: Figure 3.19Smart Fan Mode Configuration
Figure 3.19 Smart Fan Mode Configuration System Smart Fan1-3 To enable or disable system smart fan1~3. CPU Smart Fan To enable or disable CPU smart fan. System Smart Fan4 To enable or disable system smart fan4. ASMB-782 User Manual... -
Page 55: Serial Port Console Redirection
3.4.10 Serial Port Console Redirection Figure 3.20 Serial Port Console Redirection Console Redirection Enable or disable the console redirection feature. Figure 3.21 Console Redirection Setting ASMB-782 User Manual... - Page 56 Terminal Type Select a terminal type to be used for console redirection. Options available: VT100/VT100+/ANSI /VT-UTF8. Bits per second Select the baud rate for console redirection. Options available: 9600/19200/57600/115200. Parity A parity bit can be sent with the data bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in the data bits is even.
-
Page 57: Cpu Ppm Configuration
3.4.11 CPU PPM Configuration Figure 3.22 CPU PPM Configuration EIST Enable or disable Intel Speedstep function. CPU C3 Report Enable/disable CPU C3(ACPI C2) report to OS CPU CPU C6 Report Enable/disable CPU C6(ACPI C3) report to OS CPU CPU C7 Report Enable/disable CPU C7(ACPI C3) report to OS CPU ACPI T State Enable/disable ACPI T state... -
Page 58: Chipset
Chipset Figure 3.23 Chipset 3.5.1 PCH-IO Configuration Figure 3.24 PCH-IO Configuration ASMB-782 User Manual... -
Page 59: Figure 3.25Pci Express Configuration
PCIE Wake To enable or disable PCIE to wake the system from S5. Deep Sx Power Policies Enable or disable Deep Sx feature. When Deep Sx is enabled, most power including 5VSB will be off during deep Sx for energy saving. High Precision Timer To enable or disable the high precision event timer. -
Page 60: Figure 3.26Pci Express Configuration
Figure 3.26 PCI Express Configuration PCI Express Root Port 6 and 6~8 To enable or disable PCI Express Root Port 1 or 6~8. ASPM Support To set ASPM level for PCI Express Root POrt 1 or 6~8. PCIe Speed To set PCIe speed for PCI Express 1 or 6~8. ASMB-782 User Manual... -
Page 61: Figure 3.27Usb Configuration
Figure 3.27 USB Configuration XHCI Pre-Boot Driver To enable or disable XHCI pre-boot driver support HS Port #1~4 Switchable To allow HS port switching between XHCI and EHCI. When this item is disabled, the port is routed to EHCI. If HS port is routed to XHCI, the corresponding SS port is enabled. -
Page 62: Figure 3.28Pch Azalia
Figure 3.28 PCH Azalia Azalia Control detection of Azalia device. Figure 3.29 LAN Configuration LAN1 Controller Enable or disable onboard LAN1. ASMB-782 User Manual... -
Page 63: System Agent (Sa) Configuration
Wake on LAN Enable or disable integrated LAN to wake the system. LAN1 Option-ROM Enable or disable boot options for legacy network devices. LAN2~4 Controller Enable or disable onboard LAN1. LAN2~4 Option-ROM Enable or disable boot options for legacy network devices. 3.5.2 System Agent (SA) Configuration Figure 3.30 System Agent (SA) Configuration... -
Page 64: Figure 3.31Graphics Configuration
3.5.2.1 Graphics Configuration Figure 3.31 Graphics Configuration Primary Display To select which graphics device, IGFX/PEG/PCI should be primary display or select SG for switchable Gfx. Internal Graphics To enable/disable/Auto internal graphics. GTT Size This item sets the amount of main memory that is pre-allocated to support the Inter- nal Graphics Translation Table. -
Page 65: Figure 3.32Lan Configuration Screen
3.5.2.2 NB PCIe Configuration Figure 3.32 LAN configuration screen PEG0 - Genx To configure PEG from Gen1 to Gen3. PEG0 ASPM To control ASPM support for the PEG Device, and this item has no effect if PEG is not the currently active device. De-emphasis control To configure the De-emphasis control on PEG. -
Page 66: Figure 3.33Memory Configuration
3.5.2.3 Memory Configuration Figure 3.33 Memory Configuration ECC Support Enables or disables DDR3 ECC support. ASMB-782 User Manual... -
Page 67: Boot
Boot Figure 3.34 Boot Setup Prompt Timeout Use the <+> and <-> keys to adjust the number of seconds to wait for setup activa- tion key. Bootup NumLock State “On” or “Off” power-on state for the NumLock Quiet Boot If this option is set to Disabled, the BIOS displays normal POST messages. If Enabled, an OEM Logo is shown instead of POST messages. -
Page 68: Security
Security Figure 3.35 Security Select Security Setup from the ASMB-782 Setup main BIOS setup menu. All Security Setup options, such as password protection, are described in this section. To access the sub menu for the following items, select the item and press <Enter>. Figure 3.36 HDD Password Configuration ASMB-782 User Manual... -
Page 69: Save & Exit
HDD Password Configuration This item sets HDD password. Save & Exit Figure 3.37 Save & Exit Save changes and exit* When you have completed system configuration, select this option to save your changes, exit BIOS setup and boot into the OS so the new system configuration parameters can take effect. - Page 70 Save as User Defaults Select this option to save user's configuration. Restore User Defaults Select this option to restore BIOS to user's configuration. Boot Override This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available file system devices. *When you do some critical changes, the system will still reboot even you choose "Save changes and exit".
-
Page 71: Chapter 4 Chipset Software Installation Utility
Chapter Chipset Software Installation Utility... -
Page 72: Before You Begin
Before you begin To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for the ASMB-782 are located on the software installation CD. Note! The files on the software installation CD are compressed. Do not attempt to install the drivers by copying the files manually. -
Page 73: Windows Xp / Windows 7 Driver Setup
Windows XP / Windows 7 Driver Setup Insert the driver CD into your system's CD-ROM drive. You can see the driver folders items. Move the mouse cursor over the folder "01-Chipset". In CSI folder, you can click find an executable file to complete implementation of the driver. Click setup to execute program. - Page 74 ASMB-782 User Manual...
-
Page 75: Chapter 5 Vga Setup
Chapter VGA Setup... -
Page 76: Introduction
Introduction The 2nd Gen Intel® Core™ i processors are embedded with integrated graphics con- troller. You need to install the VGA driver to enable this function, which includes the following features: Optimized integrated graphic solution: With Intel® Graphics Flexible Display Interface, it supports versatile display options and 32-bit 3D graphics engine. -
Page 77: Chapter 6 Lan Configuration
Chapter LAN Configuration... -
Page 78: Introduction
Introduction The ASMB-782 has four Gigabit Ethernet LANs via dedicated PCI Express x1 lanes (GbE LAN1: Intel 82579LM; GbE LAN2~4: Intel 82574L (LAN3/4 is optional for G4 SKU) that offer bandwidth of up to 500 MB/sec, eliminating the bottleneck of network data flow and incorporating Gigabit Ethernet at 1000 Mbps. - Page 79 Appendix Programming the Watchdog Timer...
-
Page 80: Watchdog Timer Overview
The ASMB-782’s watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to pro- gram it. Watchdog timer overview The watchdog timer is built in to the super I/O controller NCT6776F. - Page 81 Unlock NCT6776F Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog timer Lock NCT6776F ASMB-782 User Manual...
-
Page 82: Example Programs
Table A.1: Watchdog timer registers Address of Read/ Value (2F) & description register (2E) Write Write this address to I/O address port 2E (hex) twice to unlock the 87 (hex) NCT6776F 07 (hex) write Write 08 (hex) to select register of watchdog timer. Write 01 (hex) to enable the function of the watchdog timer. - Page 83 Dec dx ; Set second as counting unit Mov al,0f5h Out dx,al Inc dx In al,dx And al,not 08h Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 10 seconds and start counting Mov al,0f6h Out dx,al Inc dx Mov al,10;...
- Page 84 Out dx,al ;----------------------------------------------------------- Dec dx ; Set timeout interval as 5 minutes and start counting Mov al,0f6h Out dx,al Inc dx Mov al,5; 5 minutes Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776F Mov al,0aah Out dx,al Enable watchdog timer to be reset by mouse ;----------------------------------------------------------- Mov dx,2eh ;...
- Page 85 ;----------------------------------------------------------- Mov dx,2eh ; unlock NCT6776F Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h...
- Page 86 Out dx,al Inc dx In al,dx Or al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; lock NCT6776F Mov al,0aah Out dx,al ASMB-782 User Manual...
- Page 87 Appendix I/O Pin Assignments...
-
Page 88: Parallel Port (Lpt1)
Parallel Port (LPT1) Table B.1: Parallel Port (LPT1) Signal Signal STROBE* GND* AFD* IGND ERR* INIT* ACK* SLIN* BUSY SLCT USB2.0 Header ( USB7~12) USB910 USB78 USB1112 Table B.2: USB Header (USB7~12) Signal Signal USB_VCC5 USB_VCC5 USB_D- USB_D- USB_D+ USB_D+ ASMB-782 User Manual... -
Page 89: Usb3.0 Header ( Usb34)
USB3.0 Header ( USB34) Table B.3: USB 3.0 Header (USB34) Signal Signal USBV2 EUSB3_P3RXN USBV2 EUSB3_P3RXP EUSB3_P4RXN EUSB3_P4RXP EUSB3_P3TXN EUSB3_P3TXP EUSB3_P4TXN EUSB3_P4TXP USB3_z_N USB3_z_P USB4_z_N USB_OC USB4_z_P VGA Connector (VGA) Table B.4: VGA Connector (VGA) Signal Signal GREEN BLUE H-SYNC V-SYNC ASMB-782 User Manual... -
Page 90: Rs-232 Interface (Com12)
RS-232 Interface (COM12) COM1 COM2 Table B.5: RS-232 Interface (COM12) COM1 COM2 Signal Signal SOUT SOUT PS/2 Keyboard and Mouse Connector (KBMS1) Table B.6: Keyboard and Mouse Connector (KBMS1) Signal KB DATA KB VCC KB CLK M_DATA M_VCC M_CLK ASMB-782 User Manual... -
Page 91: External Keyboard And Mouse Connector (Kbms2)
External Keyboard and Mouse Connector (KBMS2) Table B.7: External Keyboard and Mouse Connector (KBMS2) Signal KB CLK KB DATA MS DATA MS CLK System Fan Power Connector (SYSFAN1~4) Table B.8: Fan Power Connector (SYSFAN1/SYSFAN2) Signal +12 V DETECT Power LED (JFP1) Table B.9: Power LED (JFP1) Function LED power (3.3 V) -
Page 92: External Speaker Connector (Jfp1)
B.10 External Speaker Connector (JFP1) Table B.10: External Speaker Connector (JFP1) Function SPK_VCC SPK_OBS SPK_BUZ SPK_OUT B.11 Reset Connector (JFP1) Table B.11: Reset Connector (JFP1) Signal RESET B.12 HDD LED Connector (JFP1) Table B.12: HDD LED Connector (JFP1) Signal HDD_LED+ HDD_LED- ASMB-782 User Manual... -
Page 93: Atx Soft Power Switch (Jfp1)
B.13 ATX Soft Power Switch (JFP1) Table B.13: ATX Soft Power Switch (JFP1) Signal PWR-BTN B.14 Front panel SMBus connector (FP_SMB1) Table B.14: Front panel SMBus connector(FP_SMB1) Signal SMB_FP_ALERT SMB_FP_DATA SMB_FP_CLK +3.3 V B.15 USB/LAN ports (LAN1_USB12 and LAN2_USB34) Table B.15: USB Port Signal Signal VCC_DUAL... -
Page 94: Front Panel Audio Connector (Fpaud1)
Table B.16: Giga LAN 10/100/1000 Mbps RJ-45 port Signal Signal MID0+ MID2+ MID0- MID2+ MID1+ MID3+ MID1- MID3+ B.16 Front Panel Audio Connector (FPAUD1) Table B.17: Front Panel Audio Connector (FPAUD1) Signal MIC2_L AGND MIC2_R PRESENSE LIN2_R MIC_DEC FIO_JD LIN2_L LINEOUT2_DEC B.17 8-pin Alarm Board Connector (VOLT1) -
Page 95: Case Open Connector (Jfp1)
B.18 Case Open Connector (JFP1) Table B.19: Case Open Connector (JFP1) Signal CASEOP B.19 Front Panel LAN LED Connector (LAN_LED1/2) Table B.20: LAN LED Connector (LAN_LED1/2) Signal Signal LAN1/3_LED0_ACT LAN2/4_LED1_ACT VCC3_LAN1/3LED VCC3_LAN2/4LED LAN1/3_LED1_1000M LAN2/4_LED2_1000 LAN1/3_LED2_100M LAN2/4_LED0_100 VCC3 B.20 SPI_CN1: SPI flash card pin connector Table B.21: SPI_CN1:SPI fresh card pin connector Signal Signal... -
Page 96: System I/O Ports
B.21 System I/O Ports Table B.22: System I/O ports Addr. range (Hex) Device 000-01F DMA controller 020-021 Interrupt controller 1, programmable interrupt controller 022-03F Motherboard resources 040-05F 8254 timer 060-06F 8042 (keyboard controller) 070-07F Real-time clock, non-maskable interrupt (NMI) mask 081-09F DMA page register 0A0-0BF... -
Page 97: 1St Mb Memory Map
B.23 1st MB Memory Map Table B.24: 1st MB memory map Addr. range (Hex) Device E0000h - FFFFFh BIOS CC000h - DFFFFh Unused C0000h - CBFFFh VGA BIOS A0000h - BFFFFh Video Memory 00000h - 9FFFFh Base memory ASMB-782 User Manual... - Page 98 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2012...
