SYMPTOM POSSIBLE CAUSE
Display shows a station 7.
operating, but no watering
occurs.
8.
Station does not come on. 9.
10. A short circuit in the solenoid or valve wiring
11. Sensor system is preventing irrigation.
12. Start time has not been entered for the
13. Water Budget for the station’s program is set
66
Sensor system is preventing irrigation.
(WATERING SUSPENDED BY SENSOR light is
on.)
No sensor or jumper is connected to the
controller’s SENSOR terminals, and the
SENSOR BYPASS switch has been set to
ACTIVE.
No run time has been set for the station.
has disabled the station. (Display shows
“.AULT” and a station number, and the
.AULT light in the upper left corner of the face
panel is on.)
(WATERING SUSPENDED BY SENSOR light is
on.)
program to which the station is assigned.
to 0%.
SOLUTION
Turn the sensor bypass switch to O... If watering
resumes, the sensor is operating properly, and no
correction is necessary.
Turn the sensor bypass switch to O... To prevent
future occurrences, install the supplied jumper on
the controller’s SENSOR terminals. See page 54.
Turn the dial to the station number, and press the
PGM button to check the run times set for the
station. To add a run time, see page 19.
Identify and repair the fault in the circuit. Then press
the Clear .ault button, and start the station manually.
See page 35 for instructions.
See correction for Cause #7.
See correction for Cause #2.
See correction for Cause #6.
