Programming Checklist

To program the ESP-LX+ or LXi+ controller for the first time,
we recommend that you complete the following steps in order.
.or your convenience, a check-off box ( ) is provided for each
step.
.ill out Programming Chart .................................................. Page 8
Clear all program information ............................................... Page 10
Set time and date. ................................................................ Page 11
.or each program:
) * + ,
Select program (A, B, C, or D-drip). ... Page 13
Set watering day cycle ....................... Page 14
Set station watering times. ................. Page 19
Set program start time(s). ................... Page 21
Set water budget (optional). ............... Page 23
Set station delays (optional). .............. Page 24
ESP-LX+ & LXi+ Installation, Programming, & Operation Guide
Set master valve / pump starts for each station (optional). . Page 26
Set rain delay (optional). ...................................................... Page 28
Set calendar day(s) O.. (optional). ..................................... Page 29
Set sensor system and bypass switch (optional). ............... Page 31
Set controller to automatic operation. ................................. Page 33
Run test program (optional). ................................................. Page 36
7
