TAM2 Dimensions
(H x W x D):
25.375" x 19.375" x 0.3125" (644.6mm x 492.1mm x 7.9mm)
19.375"
(492.1mm)
0.45"
7.5" 7.5"
(11.4mm)
(190.5mm) (190.5mm)
0.156"
( 3.96mm)
25.375"
(644.6mm)
16.25"
(412.8mm)
12.625"
(320.7mm)
8.5"
(215.9mm)
1.0" (25.4mm)
1.0" (25.4mm)
7.5"
7.5"
0.45"
(190.5mm)
(11.4mm) (190.5mm)
9.2" 9.2"
(233.7mm) (233.7mm)
