Page 1 Eaton® 93PM-L UPS 20 – 200 kW (208V) UPS Installation and Operation Manual p/n: 164000724 Revision 01...
Page 2 National Fire Protection Association, Inc. All other trademarks are property of their respective companies. ©Copyright 2018 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.
Page 3: Table Of Contents
4.4 External AC Power Wiring Installation ......................76 4.5 Battery Power Wiring ..........................81 4.6 Installing Interface Connections ........................82 4.6.1 Installing Building Alarm and Relay Contact Connections ................82 Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 4 6.3.8 Transfer from Double Conversion Mode to ESS Mode ................130 6.3.9 Transfer from Double Conversion to Bypass Mode and Shut Down UPMs ............ 130 6.3.10 Single UPM Shutdown ........................131 6.3.11 Single UPM Restart ......................... 131 Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 5 1 1 0 0 W W a a r r r r a a n n t t y y ........................................................... . 1 1 4 4 9 9 10.1 Limited FACTORY WARRANTY for Three-Phase Eaton 93PM UPS and 93PM UPS Accessory Products....149...
Page 6 Table of Contents Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 7 Path of Current Through the UPS in Normal Mode................107 Figure 38. Path of Current Through the UPS in Bypass Mode................108 Figure 39. Path of Current Through the UPS in Battery Mode................109 Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 8 Figure 60. Typical EAA Control Screen ......................127 Figure 61. REPO Operation ........................134 Figure 62. Optional Minislot Cards ....................... 135 Figure 63. Air Filter Location ........................141 viii Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 9 Display Function Menu Map ......................115 Table 31. Display Menu Operation ....................... 117 Table 32. Controls Menu Operation ......................124 Table 33. Typical System Status Messages....................125 Table 34. IRC-MS Default Triggers ....................... 135 Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 10: List Of Tables
List of Tables Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 11: Ups Standard Features
AC power to protect the customer's load from power failures. The Eaton 93PM-L 200 kW, Four Wire UPS online power protection system is used to prevent loss of valuable electronic information, minimize equipment downtime, and minimize the adverse effect on production equipment due to unexpected power problems.
Page 12 Introduction Figure 1. Eaton 93PM-L UPS (200 kW, Four Wire) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 13: Control Panel
1 1 . . 1 1 . . 4 4 E E n n e e r r g g y y S S a a v v e e r r S S y y s s t t e e m m M M o o d d e e The 93PM-L Series UPS offers an Energy Saver System (ESS) mode that maximizes efficiency by eliminating unnecessary power conversion when the commercial power source is within acceptable voltage and frequency limits.
Page 14: Integrated Battery Cabinet
UPS from virtually any location within the facility, up to 300 feet from the UPS. Refer to the Eaton 93PM Remote Monitoring Device (RMD) Installation and Operation Manual, listed in paragraph , for additional information.
Page 15: Battery System
1 1 . . 2 2 . . 5 5 A A d d d d i i t t i i o o n n a a l l O O u u t t p p u u t t S S u u r r g g e e P P r r o o t t e e c c t t i i o o n n The Eaton 93PM-L UPS complies with ANSI 62.41 for line surges. However, if added security is required an additional Surge Protection Device (SPD) can be installed.
Page 16: For More Information
(WEEE) in the trash. For proper disposal, contact your local recycling/reuse or hazardous waste center. recycling/reuse or hazardous waste center. recycling/reuse or hazardous waste center. recycling/reuse or hazardous waste center. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 17 F F o o r r M M o o r r e e I I n n f f o o r r m m a a t t i i o o n n Refer to the Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded, or the Eaton 93PM...
Page 18 1 1 . . 1 1 0 0 E E q q u u i i p p m m e e n n t t R R e e g g i i s s t t r r a a t t i i o o n n Please visit www.eaton.com/pq/register to register your new Eaton UPS / Eaton UPS Accessory.
Page 19 ELECTRIC ENERGY HAZARD. Do not attempt to alter any UPS or battery wiring or connectors. Attempting to alter wiring can cause injury. • Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 20 Ne pas fumer près des accumulateurs. Ne pas produire de flamme ou d’étincelle dans la zone de l’accumulateur. Dissiper l'électricité statique de votre corps en touchant une surface reliée à la terre avant de toucher les accumulateurs. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 21: Creating An Installation Plan
Service Engineer, or the warranty terms specified in Chapter 10 Warranty become void. This service is offered as part of the sales contract for the UPS. Contact an Eaton service representative in advance (a minimum two-week notice is required) to reserve a preferred startup date.
Page 22 Sizing the site cooling infrastructure to be capable of cooling the maximum kW frame size will allow a full power rating upgrade without having to modify the infrastructure. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 23 15.26 (52063) Eaton 93PM-L 200-10 (N+1) 873 liter/sec (1850 cfm) Eaton 93PM-L 200-9 791 liter/sec (1675 cfm) 180 kW 16.16 (55126) Eaton 93PM-L 200-10 (N+1) 873 liter/sec (1850 cfm) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 24 Allow clearance in front of and on top or in back of the cabinet for proper air circulation. The clearances required around the UPS cabinet are shown in Table Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 25 From Back of Cabinet with Rear Exhaust From Back of Cabinet with Top Exhaust None Required From Right Side of Cabinet None Required None Required From Left Side of Cabinet Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 26 DISPLAY [.2] HDWR 1880 [74.0] 47.4 M10 THD (8X) [1.9] 4 EACH SIDE 58 [2.3] DOOR VENTILATION AREA 388 [15.3] 630 [24.8] 960 [37.8] Dimensions are in millimeters [inches] Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 27 BOTTOM ENTRY [25.6] CONDUIT LANDING FOR AC INPUT, AC OUTPUT AND DC 370.5 [14.6] 200.5 [7.9] 575.5 [22.7] [9.8] [5.5] 90.5 [3.6] BOTTOM VIEW Dimensions are in millimeters [inches] Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 28 M8 THD (8X) 8 EA FRT & REAR 62 [2.4] 30 [1.2] 104 [4.1] 30 [1.2] 119 [4.7] 67.5 [2.7] Dimensions are in millimeters [inches] 210.5 [8.3] 365 [14.4] Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 29 327.3 [12.9] [.9] 1120.4 [44.1] BOLTS (4X) FRONT & REAR M12 CLASS 8.8 TORQUE 66Nm 1/2" GRADE 5 TORQUE 64 LB-FT [.9] [1.3] [1.3] Dimensions are in millimeters [inches] Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 30 935 [36.8] 548 [21.6] 411 [16.2] 735 [1616] Eaton 93PM-L 200 with 9 UPMs Installed 967 [38.1] 549 [21.6] 406 [16] 766 [1685] Eaton 93PM-L 200 with 10 UPMs Installed Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 31 Refer to national and local electrical codes for acceptable external wiring practices. • To allow for future power upgrades, Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed instead of the derated kW ordered.
Page 32 DO NOT use a single feeder breaker to supply both the UPS and the maintenance bypass. • The Eaton 93PM-L 200kW UPS provides backfeed detection and protection through a shunt trip mechanism of the bypass input breaker. For external wiring recommendations, including the minimum AWG size of external wiring, see...
Page 33: Integrated Battery Cabinet Installation
(each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 34 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 35 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 36 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 37 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 38 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 39 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 40 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 41 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 42 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 43 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 44 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 45 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 46 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 47 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 48 NOTE Callout letters A, B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 49 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 50 NOTE Callout letters B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 51 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 52 NOTE Callout letters B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 53 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 54 NOTE Callout letters B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 55 (each) DC Input from External Battery (Line-Up-and-Match Eaton 93PM-L IBC-SW, IBC-LW or IBC-LHW) For Line-Up-and-Match wiring refer to Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded or Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate DC Input from External Battery...
Page 56 NOTE Callout letters B, C and D map to Figure Line-up-and-match battery wiring with a 105°C rating is factory supplied with the Eaton 93PM-L Integrated Battery Cabinet (IBC). Eaton recommends installing the UPS using wiring and external overcurrent protection breakers sized for the fully rated UPS kW frame size installed.
Page 57 Conical Washer Rectifier Input, Bypass Input, Battery Input, and Output to Critical Load NOTE For additional information and/or assistance contact an Eaton service representative (see paragraph 1.9 Getting Help). Table 19. Recommended Installation Parts and Tools (Not Supplied by Eaton)
Page 58 AC Input to UPS Bypass 208 or 220 (A, B, C, Neutral, Ground 93PM-L 200-2 30 kW AC Output 93PM-L 200-3 (N+1) (A, B, C, Neutral, Ground) Battery (Positive, Negative, Ground) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 59 AC Input to UPS Bypass 208 or 220 (A, B, C, Neutral, Ground 93PM-L 200-3 60 kW AC Output 93PM-L 200-4 (N+1) (A, B, C, Neutral, Ground) 1-1/2 Battery (Positive, Negative, Ground) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 60 AC Input to UPS Bypass 208 or 220 (A, B, C, Neutral, Ground 93PM-L 200-5 90 kW 2-1/2 AC Output 93PM-L 200-6 (N+1) (A, B, C, Neutral, Ground) Battery (Positive, Negative, Ground) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 61 AC Input to UPS Bypass 208 or 220 (A, B, C, Neutral, Ground 93PM-L 200-6 120 kW 3–1/2 AC Output 93PM-L 200-7 (N+1) (A, B, C, Neutral, Ground) Battery (Positive, Negative, Ground) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 62 (A, B, C, Neutral, Ground 2–1/2 220 Vac 93PM-L 200-8 150 kW AC Output 93PM-L 200-9 (N+1) 208 or 220 (A, B, C, Neutral, Ground) 1–1/2 Battery (Positive, Negative, Ground) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 63 AC Input to UPS Bypass 208 or 220 (A, B, C, Neutral, Ground 93PM-L 200-9 180 kW 3-1/2 AC Output 93PM-L 200-10 (N+1) (A, B, C, Neutral, Ground) Battery (Positive, Negative, Ground) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 64 (A, B, C, Neutral, Ground 200 kW 93PM-L 200-10 AC Output (A, B, C, Neutral, Ground) Battery (Positive, Negative, Ground) NOTE Wires per conduit include neutral and ground wire. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 65 Eaton 93PM-L 200-7 130 kW Eaton 93PM-L 200-8 (N+1) 100% Rated 500A 450A 80% Rated 700A 600A Eaton 93PM-L 200-7 140 kW Eaton 93PM-L 200-8 (N+1) 100% Rated 500A 500A Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 66 To reduce the risk of fire, connect only to a circuit provided with maximum input circuit breaker current ratings from Table 21 in accordance with the NEC, ANSI/NFPA 70. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 67 Eaton 93PM-L 200-7 130 kW Eaton 93PM-L 200-8 (N+1) 100% Rated 400A 350A 80% Rated 500A 500A Eaton 93PM-L 200-7 140 kW Eaton 93PM-L 200-8 (N+1) 100% Rated 400A 400A Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 68 100% Rated 500A 500A 80% Rated 700A 190 kW Eaton 93PM-L 200-10 100% Rated 600A 500A 80% Rated 700A 700A Eaton 93PM-L 200-10 200 kW 100% Rated 600A 600A Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 69 300A Eaton 93PM-L 200-8 (N+1) Eaton 93PM-L 200-7 140 kW 100% Rated 350A Eaton 93PM-L 200-8 (N+1) Eaton 93PM-L 200-8 150 kW 100% Rated 350A Eaton 93PM-L 200-9 (N+1) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 70 Program the battery detect building alarm to read battery open and for normally open contacts. • A supplemental 48 Vdc shunt trip signal for the battery disconnect device is provided, but is not required for normal operation. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 71 Carefully inspect the outer packaging for evidence of damage during transit. CAUTION Do not install a damaged cabinet. Report any damage to the carrier and contact an Eaton service representative immediately. NOTE For the following step, verify that the forklift or pallet jack is rated to handle the weight...
Page 72 Inspect the contents for any evidence of physical damage, and compare each item with the Bill of Lading. If damage has occurred or shortages are evident, contact an Eaton service representative immediately to determine the extent of the damage and its impact on further installation.
Page 73 UPS Installation Plan and Unpacking Figure 8. UPS Cabinet as Shipped on Single Pallet Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 74 UPS Installation Plan and Unpacking Figure 9. UPS Cabinet and Wireway as Shipped on Two Pallets Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 75 12. Place a floor protector from the parts kit underneath each jacking bolt, and screw the bolts down against them. The floor protectors protect the floor from being marred by the jacking bolts. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 76 Skid Mounting Bolts (8 places front) (8 places rear) Left Side Cabinet Support Jacking Bolts Pallet Skid (2 places front) (2 places rear) Floor Protectors (2 places front) (2 places rear) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 77 (6 places front) (6 places rear) Skid Mounting Bolts (6 places front) (6 places rear) Jacking Bolts (2 places front) (2 places rear) Floor Protectors (2 places front) (2 places rear) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 78 Jacking Bolts Caster Outrigger (4 places rear) (2 places front) (2 places left side) (2 places rear) (2 places right side) Floor Protectors (2 places front) (2 places rear) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 79 CAUTION To prevent tipping when rolling the cabinet, push the cabinet from the rear whenever possible. 16. Roll the cabinet and Wireway, if applicable, to the final installation location. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 80 UPS, remove the following: Wireway Hang Panel, Deadfront, Deadfront Top Brace, and left Front Corner Post, Retain all hardware for later use. See Figure Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 81 200kW Wireway with Panels and Post removed Deadfront Top Brace Top Strap Back and Base Straps (2x stacked) Wireway Left Front Corner Deadfront Post - Removed Wireway Hang Panel Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 82 Caster Outrigger (2 places left side) (2 places right side) 23. Remove the UPS cabinet’s right Front Corner Post, see Figure 15, recycle the hardware in a responsible manner. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 83 26. Using the Top Strap, the Back Strap and the Base Strap removed in Step 20 and the retained hardware, attach the Wireway to the UPS cabinet, see Figure 16 Figure 17 for strap installation locations. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 84 Figure 16. UPS Top and Back Strap Install Locations TOP VIEW TOP VIEW (TOP EXHAUST OPTION) (REAR EXHAUST OPTION) TOP STRAP INSTALL LOCATION BACK VIEW BACK VIEW (REAR EXHAUST OPTION) (TOP EXHAUST OPTION) BACK STRAP INSTALL LOCATION Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 85 29; if using the front and rear floor mounting brackets, proceed to Step 33; otherwise, proceed to Step 29. Locate the customer supplied left and right side floor mounting brackets and hardware. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 86 I I n n t t e e g g r r a a t t e e d d B B a a t t t t e e r r y y C C a a b b i i n n e e t t I I n n s s t t a a l l l l a a t t i i o o n n If installing Integrated Battery Cabinets (IBCs), refer to the Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate, or the Eaton 93PM Integrated Battery Cabinet-Small Welded IBC-SW (432V and 480V) Installation Manual, listed in paragraph 1.8, for installation instructions.
Page 87 Figure 21 for UPS terminal locations. For a detailed view of the UPS ground terminals, see Figure 12. Proceed to paragraph 4.5 Battery Power Wiring. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 88 CONDUIT LANDING CONDUIT FOR AC INPUT, AC PLATE OUTPUT AND DC BOTTOM VIEW BOTTOM ENTRY CONTROL WIRING CONDUIT PLATE BOTTOM ENTRY CONDUIT LANDING FOR AC INPUT, AC OUTPUT AND DC Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 89 Figure 20. UPS Inter-Cabinet Wiring Access Location Inter-cabinet wiring access to route interface wiring between cabinets. Inter-cabinet wiring access knockouts. Remove knockouts as required to route power wiring between cabinets. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 90 SWITCH RECTIFIER ACCESS 20kW POWER MODULE AC OUTPUT QTY 1-10 MODULES TO LOAD CONFIGURABLE DC INPUT BATTERY START UPM SLIDE LOCK (2X) GROUND STUDS FOR CABINET TO CABINET WIRING Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 91 B B a a t t t t e e r r y y P P o o w w e e r r W W i i r r i i n n g g CAUTION When sizing the battery system, do not exceed the internal battery charger capabilities. See Chapter 9, “Product Specifications,” for maximum battery charger currents. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 92 Route and connect the battery cables between the UPS and battery cabinet or battery disconnect according to the instructions in the Eaton 93PM Universal Integrated Battery Cabinet Installation Manual- Large and Large High Rate, or the Eaton 93PM Integrated Battery Cabinet-Small Welded IBC-SW (432V and 480V) Installation Manual, Connect the positive, negative, and ground DC power wiring from the battery cabinet or disconnect to the UPS cabinet battery and ground terminals.
Page 93: Generator Interface Connections
4.6.6 Installing Minislot Interface Connections; if wiring REPO connections, proceed to paragraph 4.7 Installing a REPO Switch; otherwise, proceed to Step 16. Close the UPS outside door and secure the latch. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 94 UPS System Installation Figure 23. Interface Terminal Locations MINI SLOT COMMUNICATION BAYS CANBUS TERMINALS INTERFACE TERMINALS SHUNT TRIP TERMINAL LOCATION Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 95 UPS System Installation Figure 24. Interface Terminal Detail CUSTOMER CAN RS232 RELAY OUTPUT CUSTOMER INPUT ALARMS Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 96 UPS System Installation Figure 25. Bottom Access Interface Wiring Location Wire Tie Anchors Bottom Access Interface Wiring Channel Bottom Entry Conduit Landings for Customer Interface Wiring Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 97 Building Alarm 5 Input: Programmable UPS Twisted Pair 2 lb in alarm, activated by a remote Wires #18 AWG #14 #30 AWG (0.22-0.25 Nm) Building Alarm 5 Return dry contact closure Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 98 If installing interface wiring connections between standalone cabinets, conduit must be installed between cabinets. NOTE 5 Disconnect terminal block plugs from terminal blocks to wire plugs. To install wiring: Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 99 25). Refer to the Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate, or the Eaton 93PM Integrated Battery Cabinet-Small Welded IBC-SW (432V and 480V) Installation Manual, listed in paragraph 1.8, for battery cabinet wiring access information and instructions.
Page 100 Figure 30 for UPS terminal locations. Refer to the Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate, or the Eaton 93PM Integrated Battery Cabinet-Small Welded IBC-SW (432V and 480V) Installation Manual, listed in paragraph , for battery cabinet wiring access information and instructions.
Page 101: Installing A Repo Switch
11. Reinstall safety shield panel and secure with the retained hardware. 12. Reinstall the wireway hang panel and secure with the retained hardware. 13. Close the UPS outside door and secure the latch. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 102 UPS System Installation Figure 29. Shunt Trip Terminal Location UPS RIGHT SIDE VIEW UPS FRONT VIEW (WIREWAY IS REMOVED TO SHOW DETAIL) SHUNT TRIP TERMINAL LOCATION Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 103 Output: Contacts used to Shunt Trip – 2 lb in Twisted Pair Wires open battery breaker or #14 #30 AWG #18 AWG (0.22-0.25 Nm) 48 Vdc Battery disconnect Shunt Trip + Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 104 14. If wiring Minislot connections, proceed to paragraph 4.6.6 Installing Minislot Interface Connections; if wiring REPO connections, proceed to paragraph Figure 31; otherwise, proceed to Step 15. Close the UPS outside door and secure the latch. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 105 NOTE 3 Remove the cabinet stiffener bar (see ) before installing or removing Minislot cards. Reinstall the bar after the procedure is completed. For installation and setup of a Minislot card, contact an Eaton service representative (see paragraph 1.9 Getting Help).
Page 106 The REPO switch must be a Normally-open or Normally-closed latching-type switch not tied into any other circuits. NOTE 4 This procedure is intended for installing the Eaton-supplied REPO switch. If installing another manufacturer's switch, use this procedure, and and as a guide. NOTE 5 The REPO switch wiring must be in accordance with NEC Article 725 Class 2 requirements.
Page 107 NEC Article 725 Class 2 requirements. 18. Close the UPS outside door and secure the latch. Figure 32. REPO Terminal Block Connector Assignments EPO_A_B EPO_A GND-ISO EPO_B Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 108 2 lb in Input: Normally-closed dry Twisted contact used to activate UPS Pair Wires (0.22- #30 AWG 4 NO GND-ISO EPO from a remote switch #18 AWG 0.25 Nm) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 109 Eaton Customer Service Engineer, or the warranty terms specified on page Warranty become void. This service is offered as part of the sales contract for the UPS. Contact an Eaton service representative in advance (usually a two-week notice is required) to reserve a preferred startup date.
Page 110 Accessories are mounted in installed locations and wiring is terminated inside the UPS cabinet. (Optional) o Air conditioning equipment is installed and operating correctly. o The area around the installed UPS system is clean and dust-free. (Eaton recommends that the UPS be installed on a level floor suitable for computer or electronic equipment.) o Adequate workspace exists around the UPS and other cabinets.
Page 111 UPS System Installation Notes _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 112 UPS System Installation Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 113 U U P P S S S S y y s s t t e e m m O O v v e e r r v v i i e e w w The Eaton 93PM-L UPS is a continuous-duty, solid-state, transformerless, three-phase, true online system that provides conditioned and uninterruptible AC power to the UPS system's output and critical load.
Page 114: Single Ups
5 5 . . 2 2 . . 1 1 M M o o d d e e s s The Eaton 93PM-L UPS supports a critical load in four different modes of operation: • In Energy Saver System (ESS) mode, commercial AC power is supplied directly to the critical load through the internal bypass and transfers automatically to Normal mode (double-conversion on demand) if an abnormal condition is detected.
Page 115: Energy Saver System Mode
Saver System Mode. ESS mode is a normal operating mode, and not an alarm condition. While the UPS is in this mode, the NORMAL light on the front display will illuminate. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 116: Normal Mode
If the UPS becomes overloaded or unavailable, the UPS switches to Bypass mode. The UPS automatically returns to Normal mode when the overload condition is cleared and system operation is restored within specified limits. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 117: Bypass Mode
Some power line filtering and spike protection is provided to the load but no active power conditioning or battery support is available to the output of the system in the Bypass mode of operation. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 118: Battery Mode
If the input power fails to return or is not within the acceptance windows required for normal operation, the battery continues discharging until a DC voltage level is reached where the inverter output can no longer Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 119 Voltage Oneline Drawing Input Output System Type UPS Model Figure 40 93PM-L 200 208 or 220 208 or 220 Single ten UPM reverse transfer UPS with external battery Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 120: Figure 40. Eaton 93Pm-L 200 Ups System Oneline
2. DASHED LINES INDICATE OPTIONAL UPM'S. CONFIGURABLE FROM 1-10 UPMS. BREAKER EXTERNAL 3. BACKFEED PROTECTION IS NOT PROVIDED AS A PART OF UPS. CUSTOMER BATTERY SUPPLIED BYPASS INPUT BREAKER WITH 48-60VDC SHUNT TRIP IS REQUIRED. CABINET Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 121 UPS. For a description of the UPS control panel functions, and how to control and monitor UPS operation, see paragraph 6.2 Using the Control Panel. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 122: Figure 41. Ups Controls And Indicators
UPS Operating Instructions Figure 41. UPS Controls and Indicators CONTROL PANEL DOOR LATCH Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 123: Figure 42. Ups Control Panel
The four symbols on the bottom of the control panel are status indicators. These colored light emitting diode (LED) lamps work with the alarm horn to provide the operating status of the UPS. Table 29 describes the status indicators. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 124: System Events
All functions and commands are accessed by touching or tapping the screen tabs or buttons. When text input is required, either a Qwerty keyboard or numeric keypad will be displayed. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 125: Figure 43. Parts Of The Lcd
Table 30. Display Function Menu Map Menu Option Description HOME Displays the system status both graphically (mimic) and written. METERS Displays performance meters for the system or critical load. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 126: Figure 44. Main Menu And Mimic Screen
6 6 . . 2 2 . . 6 6 D D i i s s p p l l a a y y M M e e n n u u O O p p e e r r a a t t i i o o n n 6.2.6 Display Menu Operation describes the menu functions and how to use them. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 127 Configurable system settings. Tap the SETTINGS tab on the main menu navigation bar to display the settings screen. Settings may be password restricted. Settings Level 2 default password is 0101. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 128: Figure 45. Typical Meters Summary Screen
Figure 53). Statistics Details Tap the desired statistic button to display the detailed statistic screen. Controls See paragraph 6.2.8 System Controls for details. Figure 45. Typical Meters Summary Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 129: Figure 46. Typical Active Events Screen
UPS Operating Instructions Figure 46. Typical Active Events Screen Figure 47. Typical System Log Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 130: Figure 48. Typical Settings User Screen
UPS Operating Instructions Figure 48. Typical Settings User Screen Figure 49. Typical Information Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 131: Figure 50. Typical About Screen
UPS Operating Instructions Figure 50. Typical About Screen Figure 51. Typical Settings Configuration 1 Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 132: Figure 52. Typical Settings Configuration 2 Screen
UPS Operating Instructions Figure 52. Typical Settings Configuration 2 Screen Figure 53. Typical Statistics Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 133: Figure 54. Sign In Password Screen
Level 1 default password is 1111. Settings Level 2 default password is 0101. Sign in is complete. Tap continue to return to previous screen. Figure 54. Sign In Password Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 134: Figure 55. Sign In Keypad
UPS to Double Conversion mode from Bypass mode. Bypass GO TO BYPASS starts the UPS in Bypass mode or transfers the UPS to Bypass mode from Double Conversion mode. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 135: Figure 56. Typical System Control Screen
RUN BATTERY TEST starts the battery test. Table 33. Typical System Status Messages Message Function Double Conversion; Bypass; ESS Bypass Off; On; Available Charger Charger Resting; Charger Figure 56. Typical System Control Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 136: Figure 57. Typical Ups Control Screen
UPS Operating Instructions Figure 57. Typical UPS Control Screen Figure 58. Typical UPM Select Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 137: Figure 59. Typical Upm Control Screen
UPS Operating Instructions Figure 59. Typical UPM Control Screen Figure 60. Typical EAA Control Screen Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 138 S S i i n n g g l l e e U U P P S S O O p p e e r r a a t t i i o o n n NOTE 1 If an Integrated Battery Cabinet (IBC) is installed, refer to the Eaton 93PM Universal Integrated Battery Cabinet Installation Manual-Large and Large High Rate or the Eaton 93PM Integrated Battery Cabinet Installation Manual-Small Welded, listed in paragraph , for IBC battery breaker location.
Page 139 In Bypass mode, the critical load is not protected from commercial power interruptions and abnormalities. Tap the CONTROLS tab on the main menu navigation bar. The System Control screen is displayed. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 140 Tap the CONTROLS tab on the main menu navigation bar. The System Control screen is displayed. Tap the MODULES CONTROLS tab on the secondary Control menu navigation bar. The UPM Select screen is displayed. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 141 The inverter switchgear is open, and the power module is turned off. Perform the battery charger off procedure in paragraph 6.3.13 Charger Control. The rectifier and battery switchgear open. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 142 All power to the critical load is lost when LOAD OFF is selected in the following step. You should use this feature only when you want to de-energize the critical load. Tap the LOAD OFF button. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 143: Starting The Ups In Double Conversion Mode
NOTE The following instructions are for the Eaton-supplied REPO switch. If a customer- supplied REPO switch is used, it may not activate in the same manner; refer to the operating instructions provided with the switch.
Page 144: Figure 61. Repo Operation
Power is present inside the UPS cabinet until the upstream input feeder circuit breakers and battery breakers are opened. Figure 61. REPO Operation Activated Deactivated (Pushbutton locked into place.) (Unlock pushbutton to release.) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 145: Figure 62. Optional Minislot Cards
C C h h a a p p t t e e r r 7 7 C C o o m m m m u u n n i i c c a a t t i i o o n n This chapter describes the communication features of the Eaton 93PM-L UPS. For terminal wiring information, see paragraph 3.2.3 UPS System Interface Wiring Preparation...
Page 146: General Purpose Relay Contact
It’s also powered by CA Technologies, bringing together the best in hardware and software. PredictPulse Service is included at no charge during the first year of Eaton 93PM-L UPS operation (warranty period) along with the required connectivity parts. Beyond that, it may be purchased with Eaton Support Agreements or as a standalone subscription after the initial warranty expires.
Page 147 Real-time alarm events for all subscribed devices via the PredictPulse mobile app (Apple and Android). You can track all alarms by device. As critical alarms occur, Eaton will acknowledge them so you know when Eaton has diagnosed the alarm (and pending notification of resolution).
Page 148 Communication Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 149 Each battery string is an energy source in itself. DO NOT ATTEMPT TO ACCESS ANY INTERNAL AREA OF THE BATTERY STRING YOURSELF. VOLTAGES ARE ALWAYS PRESENT IN THE BATTERY STRING. If you suspect that a battery string needs service, contact an Eaton service representative. Observe these precautions when working on or around batteries: •...
Page 150 Ensure the UPS is in Normal mode (Normal status indicator is illuminated). If an alarm lamp is illuminated or the Normal status indicator is not illuminated, contact an Eaton service representative. 8 8 . . 2 2 . . 2 2 M M O O N N T T H H L L Y Y M M a a i i n n t t e e n n a a n n c c e e...
Page 151: Figure 63. Air Filter Location
Particular attention should be given to the compression lug connections. Maintenance procedures should specify that the compression lug connections be retorqued to values listed in this manual. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 152: Battery Maintenance
Eaton, Powerware, and BladeUPS are registered trademarks of Eaton Corporation or its subsidiaries and affiliates. Phillips and Pozidriv are registered trademarks of Phillips Screw Company. Copyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.
Page 153 M M a a i i n n t t e e n n a a n n c c e e T T r r a a i i n n i i n n g g A basic training course, available from Eaton, gives you a competent working knowledge of the UPS system operation and teaches you how to perform first level corrective maintenance.
Page 154: Ups Maintenance
UPS Maintenance Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 155: Models
Eaton 93PM-L 200-10 (N+1) Eaton 93PM-L 200-5 85 kW 185 kW Eaton 93PM-L 200-10 Eaton 93PM-L 200-6 (N+1) Eaton 93PM-L 200-5 90 kW 190 kW Eaton 93PM-L 200-10 Eaton 93PM-L 200-6 (N+1) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 156: Product Specifications
< 2.5° for 100% maximum load imbalance (linear load) Frequency Regulation 0.1 Hz free running Synchronous to Bypass ± 4 Hz (default setting) Frequency Slew Rate 1 Hz per second (default setting) Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 157 Meets IEC 61000-4-2 Level 3 specifications and CISPR 24. Withstands up to 4 kV (ESD) contact pulse without damage and with no disturbance or adverse effect to the critical load. Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 158 Product Specifications Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 159 For Product installed (and currently located) outside the fifty (50) United States and the District of Columbia, if, in the opinion of Eaton, a Warranted Item is defective, Eaton's sole obligation, at the option of Eaton, will be to refurbish or replace such defective Warranted Item (not including the costs of labor coverage). The defective Warranted Item will be refurbished or replaced onsite at the End-User's location or such other location as determined by Eaton.
Page 160 Eaton shall not be responsible for failure to provide service or parts due to causes beyond Eaton's reasonable control. In no case will Eaton's liability under this Warranty exceed the replacement value of the Warranted Items.
Page 161 Warranty Eaton 93PM-L 20–200kW (208V) UPS Installation and Operation Manual 164000724—Rev 01...
Page 162 16400072401 164000724 01...

Eaton 93PM-L Installation And Operation Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Eaton 93PM-L

Summary of Contents for Eaton 93PM-L

Table of Contents
