WL-108 Wireless Network Modem/router 11M
• The WLAN LED should be ON
Top LEDs
Power
Status (Red)
On - Power
On - Error
on.
condition.
Off –
Off - Normal
operation.
No Power.
Blinking - This
LED blinks
during start up.
LAN
WAN
Link/Act
On –
On -
Connection to
Corresponding
the modem
LAN (hub) port
attached to
is active.
the WAN
(Internet)
Off - No active
port is
connection on
established.
the
corresponding
Flashing -
LAN (hub) port.
Data is being
transmitted
Flashing -
or received
Data is being
via the WAN
transmitted or
port. For each
received via the
port, there
corresponding
are 2
LAN (hub) port.
100
On -
Corresponding
LAN (hub) port
is using
100BaseT.
Off -
Corresponding
LAN (hub) port
connection is
using 10BaseT,
or no active
connection.
WLAN LED
(Link/Activity
)
On - Wireless
connection is
available, but
Idle (no
traffic).
Off - Error - No
Wireless
connection
available.
Flashing -
Data is being
transmitted or
received via the
Wireless access
point. This
includes
"network
traffic" as well
as user data.
LEDs
9
