WL-108 Wireless Network Modem/router 11M
Internet access
Windows 98/ME/2000
• In the Taskbar, click on the Start button and select Settings - Control
Panel - Internet options.
• Select the tab page Connections and click on the button Settings.
• Select "I want to configure my Internet connection manually" or "I
want to make a connection via a LAN network" and click on "Next >".
• Select "I want to connect via a LAN network" and click on "Next >".
• Check carefully that all of the checkboxes in the screen Internet
configuration for a LAN have not been checked.
• Continue with the steps in the wizard, until the task is completed.
• The configuration is now completed.
Windows XP
•
In the Taskbar, click on the Start button and select - Settings –
Control Panel - Internet options.
•
Select the tab Connections and click the Setup... button.
•
When the New Connection Wizard starts, click on Next.
•
Select Connect to internet and click on Next.
•
Select Set up my connection manually and click on Next.
•
Select Connect using a broadband connection that is always on and
click on Next.
•
Click on Finish to close the Wizard.
•
In the Taskbar, click on the Start button and select - Settings –
Control Panel - Internet options.
•
Select the Connections tab and click on the LAN Settings button.
•
Check carefully that none of the boxes in the Local Area Network
(LAN) Settings window are checked.
•
The configuration is now completed.
Accessing AOL
To access AOL (America On Line) through the WL-108/109, the AOL for
Windows software must be configured to use TCP/IP network access,
rather than a dial-up connection. The configuration process is as follows:
•
Start the AOL for Windows communication software. Ensure that it is
Version 2.5, 3.0 or later. This procedure will not work with earlier
versions.
•
Click the Setup button.
•
Select Create Location, and change the location name from "New
Locality" to "WL-108/109".
•
Click Edit Location. Select TCP/IP for the Network field. (Leave the
Phone Number blank.)
•
Click Save, then OK.
Configuration is now complete.
•
Before clicking "Sign On", always ensure that you are using the "WL-
108/109" location.
15
