Virtual Servers Screen - Sitecom WL-108 Full Manual

Virtual Servers Screen

The Virtual Servers screen is reached by the Virtual Servers link on the
Advanced screen. An example screen is shown below.
This screen lists a number of pre-defined Servers, and allows you to define
your own Servers. Details of the selected Server are shown in the
"Properties" area.
Data - Virtual Servers Screen
Servers
Servers
Properties
Enable
PC (Server)
WL-108 Wireless Network Modem/router 11M
This lists a number of pre-defined Servers, plus any Servers you
have defined. Details of the selected Server are shown in the
"Properties" area.
Use this to Enable or Disable support for this Server, as required.
• If Enabled, any incoming connections will be forwarded to the
selected PC.
• If Disabled, any incoming connection attempts will be blocked.
Select the PC for this Server. The PC must be running the
appropriate Server software.
For each entry, the PC must be
running the appropriate Server
software.
If the desired Server type is not
listed, you can define your own
Servers, using the Firewall Rules.
From the Internet, ALL Virtual
Servers have the IP Address
allocated by your ISP.
42
