WL-108 Wireless Network Modem/router 11M

LAN Screen

Click LAN tab In the HOME menu to reach the LAN screen An example
screen is shown below.
Data - LAN Screen
TCP/IP
IP Address IP address for the WL-108/109, as seen from the local LAN. Use the
default value unless the address is already in use or your LAN is using
a different IP address range. In the latter case, enter an unused IP
Address from within the range used by your LAN.
Subnet Mask The default value 255.255.255.0 is standard for small (class "C")
networks. For other networks, use the Subnet Mask for the LAN
segment to which the WL-108/109 is attached (the same value as the
PCs on that LAN segment).
•
DHCP Server
•
•
See the following section for further details on using DHCP.
Buttons
Save Save the data on screen.
If Enabled, the WL-108/109 will allocate IP Addresses to PCs
(DHCP clients) on your LAN when they start up. The default (and
recommended) value is Enabled.
If you are already using a DHCP Server, this setting must be
Disabled, and the existing DHCP server must be re-configured to
treat the WL-108/109 as the default Gateway. See the following
section for further details.
The Start IP Address and Finish IP Address fields set the
values used by the DHCP server when allocating IP Addresses to
DHCP clients. This range also determines the number of DHCP
clients supported.
23
