Rear Panel

Power port
Connect the supplied
power adapter here.
WL-108 Wireless Network Modem/router 11M
10/100BaseT
LAN connections
Use standard LAN This button has two
cables (RJ45 (2) functions:
connectors) to
Reboot. When
connect your PCs to
pressed and
these ports.
released, the WL-
Note: 108/109 will reboot
(restart).
Any LAN port on the
Diagnostic print-
WL-108/109 will
out. If held down
automatically
for 3 seconds, a
function as an
diagnostic print-out
"Uplink" port when
will be sent to the
required. Just
attached printer.
connect any port to
Ensure the printer is
a normal port on the
ready before doing
other hub, using a
this.
standard LAN cable.
Clear All Data.
This button can also
be used to clear ALL
data and restore ALL
settings to the
factory default
values.
To Clear All Data
and restore the
factory default
values:
Power Off.
Hold the Reset
Button down while
you Power On.
Keep holding the
Reset Button for a
few seconds, until
the RED Status LED
on the front panel
has flashed TWICE.
Release the Reset
Button. The WL-
108/109 is now
using the factory
default values.
Reset Button WAN port
(10/100BaseT)
Connect this port to
your ADSL line.
