WL-108 Wireless Network Modem/router 11M
"Connection
Details"
Button
LAN
IP Address
Network Mask
DHCP Server
MAC Address
Wireless
Name (SSID)
Region
Channel
Wireless AP
Broadcast Name
System
Device Name
Firmware
Version
Buttons
Connection
Details
Attached
Devices
Restart
Refresh Screen
Click this button to open a sub-window and view a detailed
description of the current connection. Depending on the type of
connection, a "log" may also be available.
The IP Address of the WL-108/109.
The Network Mask (Subnet Mask) for the IP Address above.
This shows the status of the DHCP Server function - either
"Enabled" or "Disabled".
For additional information about the PCs on your LAN, and the IP
addresses allocated to them, use the PC Database option on the
Advanced menu.
This shows the MAC Address for the WL-108/WL-109 Wireless
ADSL Router, as seen on the LAN interface.
If using an ESS (Extended Service Set, with multiple access
points) this ID is called an ESSID (Extended Service Set
Identifier).
The current region, as set on the Wireless screen.
This shows the Channel currently used, as set on the Wireless
screen.
This indicates whether or not the Wireless Access Point feature is
enabled.
This indicates whether or not the SSID is Broadcast. This setting
is on the Wireless screen.
This displays the current name of the WL-108/109.
The current version of the firmware installed in the WL-108/109.
View the details of the current Internet connection. The sub-
screen displayed will depend on the connection method used. See
the following sections for details of each sub-screen.
This will open a sub-window, showing all LAN and Wireless
devices currently on the network.
Clicking this button will restart (reboot) the WL-108/109. All
existing connections though the WL-108/109 will be terminated,
but will usually re-connect automatically.
Update the data displayed on screen.
31
