WL-108 Wireless Network Modem/router 11M
Introduction
Congratulations on the purchase of your new WL-108/109 Broadband
Router. The WL-108/109 is a multi-function device providing the following
services:
•
ADSL Modem.
•
Shared Broadband Internet Access for all LAN users.
•
Wireless Access Point for 802.11b and 802.11g Wireless Stations.
•
4-Port Switching Hub for 10BaseT or 100BaseT connections.
WL-108/109 Features
The WL-108/109 incorporates many advanced features, carefully designed
to provide sophisticated functions while being easy to use.
Internet Access Features
•
Shared Internet Access. All users on the LAN or WLAN can access
the Internet through the WL-108/WL-109 Wireless ADSL Router, using
only a single external IP Address. The local (invalid) IP Addresses are
hidden from external sources. This process is called NAT (Network
Address Translation).
•
Built-in ADSL Modem. The WL-108/WL-109 Wireless ADSL Router
has a built-in ADSL modem, supporting all common ADSL connections.
•
IPoA, PPPoE, PPPoA, Direct Connection Support. The WL-
108/WL-109 Wireless ADSL Router supports all common connection
methods.
•
Auto-detection of Internet Connection Method. The WL-108/WL-
109 Wireless ADSL Router can test your ADSL and Internet connection
to determine the connection method used by your ISP.
•
Fixed or Dynamic IP Address. On the Internet (WAN port)
connection, the WL-108/WL-109 Wireless ADSL Router supports both
Dynamic IP Address (IP Address is allocated on connection) and Fixed
IP Address.
Advanced Internet Functions
•
Application Level Gateways (ALGs). Applications which use non-
standard connections or port numbers are normally blocked by the
Firewall. The ability to define and allow such applications is provided, to
enable such applications to be used normally.
•
Virtual Servers. This feature allows Internet users to access Internet
servers on your LAN. The required setup is quick and easy.
•
URL Filter. Use the URL Filter to block access to undesirable Web sites
by LAN users.
•
Logs. Define what data is recorded in the Logs, and optionally send
log data to a Syslog Server. Log data can also be E-mailed to you.
•
Firewall. As well as the built-in firewall to protect your LAN, you can
define Firewall Rules to determine which incoming and outgoing traffic
should be permitted.
•
Dynamic DNS Support. DDNS, when used with the Virtual Servers
feature, allows users to connect to Servers on your LAN using a Domain
Name, even if you have a dynamic IP address which changes every
time you connect.
5
