8.4.

Multiple XML/JSON Access

In this mode the password should be passed as non-encrypted parameter with
each request:
http://192.168.1.100/current_state.xml?pw=admin&Output1=1&PWM2=23&Out
put16=0&Pulse5=20&Count2=0
http://192.168.1.100/current_state.json?pw=admin&Output1=1&PWM2=23&Ou
tput16=0&Pulse5=20&Count2=0
Multiple XML/JSON Access is not allowed when Encrypt XML/JSON
Password option is enabled.
8.5.

Parameters

After a login the custom application can also control the DAEnetIP4 by sending
parameters (name/value pairs) with the HTTP request.
Valid parameters and values are shown in the bellow table.
Name
i
Output
PWMi
Pulsei
Counti
SetAll
pw
Value
0
1
2
0...100
1...65535
0...65535
0...65535
password
DAEnetIP4 User Manual
Table 9. Valid HTTP parameters
Description
Switch the Output Off
Switch the Output ON
Toggle the Output state
PWM Outputi
(i=1...2)
Generate pulse
output (i=1...16)
Set the counter value for
a digital input (i=1...8)
Set all the digital outputs
via single parameter
Required at login
08 June 2018
value
to an
-47-
