4.4.1 UPDI
The UPDI interface uses one pin to communicate with the target. For further information on how to use
the programming and debugging capabilities of the EDBG, see
Table 4-10. UPDI Connections
ATmega4809 Pin
UPDI
PF6
Info: PF6 (RESET) is usually not used by the EDBG as the ATmega4809 can be reset through
the UPDI interface.
4.4.2 Virtual COM Port
The Embedded Debugger acts as a Virtual Com Port gateway by using one of the ATmega4809 UARTs.
For further information on how to use the Virtual COM port, see
Table 4-11. Virtual COM Port Connections
ATmega4809 Pin
PC0
PC1
4.4.3 Data Gateway Interface
The Embedded Debugger features a Data Gateway Interface (DGI) by using either an SPI or I
DGI can be used to send a variety of data from the ATmega4809 to the host PC. For further information
on how to use the DGI interface, see
Table 4-12. DGI Interface Connections when using SPI
ATmega4809 Pin
PF3
PA4
PA5
PA6
Table 4-13. DGI Interface Connections when using I
ATmega4809 Pin
PC2
PC3
Four GPIO lines are connected to the Embedded Debugger. The EDBG can monitor these lines and time
stamp pin value changes, which make it possible to accurately time-stamp events in the ATmega4809
©
