Figure 1-1. ATmega4809 Xplained Pro Evaluation Kit Overview
CURRENT MEASUREMENT
HEADER
USER LED0
TARGET VOLTAGE
SELECT HEADER
ATECC508A
CRYPTO DEVICE
©
2018 Microchip Technology Inc.
ATmega4809 Xplained Pro
EXTENSION 3 HEADER
User Guide
SW0 USER BUTTON
RESET BUTTON
DEBUG USB
POWER HEADER
AVR DEBUG
FOR EXTERNAL
DEBUGGER
EXTENSION 1 HEADER
32.768kHz Crystal
ATmega4809
mikroBUS™ socket
EXTENSION 2 HEADER
DS50002716A-page 5
