Single-Wide Chassis

The older, single-wide 4-Slot and 8-Slot chassis have two ejector tabs for each
module, as shown in Figure
1
2
3
4
Two ejector tabs per module
Figure 1-1 Single-Wide Chassis

Dual-Wide Chassis

The newer, dual-wide chassis have one ejector tab for each module (except for
the CEC module slot, which has two ejector tabs), as shown in
dual-wide chassis has a removeable center column, which allows for the
installation of extended-format modules.
1
2
3
4
One ejector tab per module
Figure 1-2 Dual-Wide Chassis
