14 With the cover off, check the status of the LEDs on the flash memory drive.
All the LEDs should light simultaneously and then extinguish one by one.
LEDs
For more information on the flash memory drive's LEDs, see
15 If you have a blank flash memory card and need to format it and install the
software, complete the procedures in
16 If you have preinstalled software on your flash memory card, or have finished
the procedures in Chapter
from the outlet and chassis.
17 Replace the cover.
a Slide the cover toward the front of the chassis and secure the cover to the
chassis with up to 17 screws. Your chassis may have fewer than 17 screws.
b If your system has rack-mount brackets, screw in the three screws that
secure each bracket.
18 If the NETBuilder II system was mounted in a rack, remount it in the rack.
19 Plug the power cord into the outlet and chassis and turn on your NETBuilder II
system.
Use the following procedure to install the flash memory drive in the single-wide
NETBuilder II 8-Slot chassis.
Identify your chassis by the assembly part number: 20-0125-xxx. See
"Identifying Your System"
NETBuilder II chassis.
You will need a #2 Phillips screwdriver.
To Install the flash memory drive, follow these steps:
1 Turn off the system and unplug the power cord from the outlet and the chassis.

Installing in the Single-Wide 8-Slot Chassis

S/N IBPXXXX
Chapter 2.
2, turn off the power, then remove the power cord
for more information on single-wide and dual-wide
1-17
Chapter 3.
