Installing in the
Extended Chassis
Use the following procedure to install the flash memory drive in the
NETBuilder II Extended chassis.
You will need a #2 Phillips screwdriver.
To Install the flash memory drive, follow these steps:
1 Turn off the system and unplug the power cord(s) from the outlet and the
chassis.
2 Remove the front bezel.
3 Remove the filler panel above the floppy drive.
There are two slots on the Extended chassis for floppy or flash memory drives.
The top slot (shown below with the filler panel) is for drive A. The bottom slot
is for drive B. This manual shows the flash memory drive installed in drive A, the
default boot drive for the NETBuilder II system.
a
Loosen screws
on filler panel.
b
Slide filler panel
out along guide rails.
Installing in the Extended Chassis
1-25
