3-2 C 3: F M
HAPTER LASH
Self-Test
Specifications
D C
EMORY RIVE OMPONENTS
Table 3-1 LEDs
LED
LED CR 2
LED CR 3
LED CR 4
LED CR 5
All four LEDs are involved in the flash memory drive self-test mode. During
self-test, all the LEDs should light simultaneously and then extinguish one by
one. LED CR 3 then lights and stays on when the flash memory card has been
formatted on a NETBuilder II system. Facing the front of the NETBuilder II
system, LED CR 3 is the second from the left. If your LEDs do not light as
specified during a self-test, refer to
The LEDs are only visible with the cover off the 4- and 8-Slot chassis, and the
bezel off the Extended chassis.
Each LED indicates a separate self-test, as shown in
Table 3-2 LEDs Self-Tests
LED
LED CR 2
LED CR 3
LED CR 4
LED CR 5
The flash memory drive has a maximum current consumption of 1.5 amp at +5
volt. Table 3-3 lists the physical attributes of the flash memory drive.
Table 3-3 Physical Attributes
Attribute
Length
Width
Height
Weight
Normal Behavior Indicates
Off Motor on
On Flash format is recognized
Off Write activity
Off Recycling activity
Chapter
Self-Test
Address Bus/Refresh
Full RAM
Data Bus
PROM checksum
Description
5.3 inches
5 inches
1 inch
4.2 ounces
4, "Troubleshooting."
Table 3-2.
