10.00 SPECIFICATIONS

153
37
40
192
Model Data
Model DTMX-200 DTMX-500 DTMX-1K
Tension Range (grams) 0.1–200.0 0 .1–500.0 50 –1000
+ 1.0% or better
Accuracy
Outer Roller Dist. (c:c) 38 mm 38 mm 38 mm
30
Outer roller spacing c:c
2.5KB–10 KB
60
20KB– 50 KB
38 65 76
15
12
48
45
All dimensions in mm
DTMX-2K DTMX- 2.5KB DTMX-5KB DTMX-10KB
200–2000 250– 2500 500 – 5000 1.00 – 10.00 Kg 2.00 –20.00 Kg
+ 1.5% or better
38 mm 100 mm 100 mm 100 mm
2.00 DTMX OVERVIEW
Outer Roller Bracket
100 mm
200 mm
Filament
Display Symbols
• PEAK
• MAX
• MIN
• BATT
Sample Holding
Clips
Thumbpiece
Material Rigidity
Selector
DTMX-20KB
Output Connector
(on end of unit)
200 mm
Filament Guide
Rollers
Middle Sensing
Roller
LCD Display
Slide Guide Plate
Thickness
Compensator
(on back of unit)
STORE Key
Field Calibration
Adjustment
Recall Key
Power/Exit Key
Data Out Key
