7.51 Signal Characteristics
Signal Baud Rate Word Length
RS-232C 4800 8-bit
7.52 Data Format
1 2 3 4 5
S T A T
CR LF
U N I T S
D A T A
M A X
M I N
P E A K
A V G
D E V
CR LF
D A T A
1
1 2
1 0 0
E
22
Parity Stop Bits EOL Delimiter
None 2-bits
6 7 8 9 10 11
I S T I C S
g
x x x
x x x
x x x
x x x
x x x
x x
x x x
x x x
x x x
N D
4. The Dip Switch Block will be located
at the top of the opening after
removing the Slide Guide Plate.
CR + LF
5.32 Setting Dip Switches
12 13 Using a small slotted screwdriver or other pointed tool, slide each of the five
(5) Dip Switches into the ON (up) or OFF (down) position as indicated in the
CR LF
illustration below for the desired setting. Dip Switch #6 is not used.
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
CR LF
Standard Memory
Standard Memory
Without Auto–
Power Off
Extended Memory
(Continuous Mode)
automatically entered
Extended Memory
(On-Demand Mode)
ON
1 2 3 4
Display Update Rate DIP-1 DIP-2
0.5 sec OFF OFF
1.0 sec ON OFF
2.0 sec OFF ON
4.0 sec ON ON
Memory Mode DIP-3 DIP-4
OFF OFF
ON ON
ON OFF
OFF ON
Factory switch:
DO NOT
TOUCH
DIP switches
DIP Switch #6
(Not Used)
5 6
Data Output DIP-5
RS-232C OFF
Digimatic ON
Data Stored in Memory
MIN, MAX, PEAK
MIN, MAX, PEAK
MIN, MAX, PEAK, AVG, STD. DEV.
plus 100 data points
MIN, MAX, AVG, STD. DEV.
plus 100 data points
