Every time move selection bar to an event in event list,cursor will move
synchronously to
"Zoom","Move","Switch"function to adjust curve to a better position, for more
information please read next sections.
The chart below describe the items in event list:
Num. Item
I Type
II Distance
III Segment
IV Loss
V T.Loss
VI Slope
VII Reflect
relevant event
Type of event(attenuation event, Reflection event or end
event)
The distance from start event to this event(Km)..
The distance from this event to last event(Km).
Loss of this event(dB)
The loss from start point to this event(dB).
Ratio of loss(from last event to this event)to distance(from
last event to this event)
Return loss of this event
49
Switch to "Event",
move selection tag to
choose event.
on curve. User
Description
could use
