Distance Measurement - ADInstruments AD5000 Manual

4.4
Measure the distance from one point to another.
Procedure：
1. Press【F1】button to active cursor function.
2. control【 】﹑【 】to move cursor A or B.
【 】 ：move left
3. Get information by following the guide below：
Reference
point
Loss between Cursor A and
Cursor B
current pulse width and
wavelength
Indicate distance of cursor A and cursor B which relative to the reference point(start event),
relative distance(km) and loss(dB) between cursor A and cursor B.

Distance Measurement

【 】 ：move right
Resolution of X axis and
Y axis
