Peak 555A User's Guide
• Mini PCI Connector
1 5V
3 Data 1
5 Data 3
7 Data 5
9 Data 7
11 5V
13 Data 9
15 Data 11
17 Data 13
19 Data 15
21 5V
23 Data 17
25 Data 19
27 Data 21
29 Data 23
31 5V
33 Data 25
35 Data 27
37 Data 29
39 Data 31
41 5V
43 CB/E1
45 CB/E3
47 FRAME#
49 IRDY#
51 5V
53 DEVSEL#
55 SERR#
57 GNT 0#
59 GNT 2#
61 PCI CLOCK
63 PCI RESET#
65 INTA#
67 INTC#
Switches and Connectors
2 Data 0
4 Data 2
6 Data 4
8 Data 6
10 Ground
12 Data 8
14 Data 10
16 Data 12
18 Data 14
20 Ground 16
22 Data 18
24 Data 20
26 Data 22
28 Data 24
30 Ground
32 Data 26
34 Data 28
36 Data 30
38 Data 32
40 Ground
42 CB/E0
44 CB/E2
46 PAR
48 TRDY#
50 Ground
52 STOP#
54 PERR#
56 REQ 0#
58 REQ 2#
60 Ground
62 PC1CLK
64 PLOCK#
66 INTB#
68 INTC#
2-11
