Peak 555A User's Guide
• VGA
64 bit/100 MHz host Interface
Shared memory 2MB, 4MB up to 8MB
CRT & Panel support
Max Res.
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
• SCSI Controller (Optional)
Adaptec AIC 7880 RISC Controller
Ultra wide SCSI support
40MB/S (Max.) transfer rate
Backward compatible with Wide SCSI, SCSI II, etc.
Drivers for DOS/Windows, windows 95/98, Windows NT, Netware,
SCO Unix
68 Pin Wide SCSI connector x 1 (option)
• LAN
MXIC's MX98725/MX98715 Ethernet controller
10 Base T/100 Base TX support, full Duplex
Complied with PCI V2.1, IEEE 802.3, IEEE 802.3U
Driver support windows95/98, windows NT 4.0/5.0, Netware, SCO Open
Server 5.0
RJ45 x1
• On Board I/O
Winbound 83977 Super I/O ON BOARD
SIO x2, with 2x 16C550 UARTs, 9 pin D-type x1, 10 Pin connector x1
PIO x1, Bi-directional, EPP/ECP support, 20 Pin x1
Floppy Disk controller: 5
720K/1.2MB/1.44MB/2.88MB support, 26 Pin x1
PCI IDE Hard Disk Interfaces: Support up to four enhanced
IDE devices up to mode 4 PIO and mode 2 DMA Master also
Support Ultra DMA/33, Ultra DMA66
On chip Keyboard, mouse controller
PS/2 Keyboard, 6 Pin mini DIN x1 for keyboard and mouse,
5 Pin header x1
On Board USB port x2 with 6 pin header x1
-
On Board 2 pin header for reset sw, 4 pin for speaker, 5 pin for keylock
-
5 pin header (keyboard)
Specifications
Color Refresh rate
True color 85 Hz
True color 85 Hz
True color 85 Hz
256 color 60 Hz
" 360K/1.2MB, 3
4/1
"
1/2
1-5
