2-2 Connectors
Connectors on the CPU Board provide interfaces to other devices.
Connector
J10
J4
IDE1
IDE2
J13
J9
J11
VGA 1
USB 1
J14
PS2
J12
JP1
JP3
SDFD1
CN1
RJ1
J2
JP2
J1
J3/J5
Switches and Connectors
Function
Key Lock Connector
Speaker Connector
Primary IDE Connector
Secondary IDE connector
FDC Connector
Printer Connector
Com2 Connector 2
VGA Connector
USB Connector
Com1 Connector 1
PS/2 Mini DIN KBD/Mouse
Connector
5 Pins KBD Connector
2 Pins HDD LED
2 Pins (RTC Clear) Connector
TFT LCD connector
NEXCOM PCI connector
Lan RJ-45 connector
IR connector
Reset Switch
GPIO connector
Power regulator input connector
