Chapter 4 Microswitches

The Teldat H/L has a block of 8 microswitches useful for maintenance tasks and testing. Here, they are only used to
load the default configuration.
This block can be found on the underside of the Teldat h/L.
These switches should not be handled by the user unless it is necessary to re-establish the default configurations.
Note
All microswitches must be in the OFF position to ensure correct operation.

4.1 Procedure to ignore the configuration

Follow these steps when you have to reject the whole router confifuration (for instance, if you cannot remember the
password):
• Turn off the device by means of the ON/OFF switch.
• Using a screwdriver, move microswitch 5 to the ON position.
• Turn the device on with the ON/OFF switch.
When the device is switched on, a message similar to the one shown below will appear on the configuration console:
**************************************************
**************************************************
**************************************************
BOOT CODE VERSION: 02.02
gzip Mar 15 2007 12:42:55
P.C.B.: C0 MASK:0C10
START FROM FLASH
BIOS CODE DUMP.....................
BIOS DATA DUMP...
End of BIOS dump
BIOS CODE VERSION: 02.02
CLK=262144 KHz
Date: 01/09/08, Wednesday
SDRAM size: 32 Megabytes
BANK 0: 32 Megabytes (detected)
I_Cache: ON
D_Cache: ON
FLASH: 16 Mb.
NVRAM: 128 Kb.
EEPROM: 2048 Bytes.
DPRAM: 8192 Bytes.
SWITCH 10/100
SECURITY ENGINE
PCI device: Host bridge
(Bus: 0, Device: 0, Function: 0)
(Subs. Vendor: 0x0000, Subs. Device: 0x0000)
Slot 1 - PCI device: serial bus controller
(Bus: 0, Device: 10, Function: 0)
(Subs. Vendor: 0x5444, Subs. Device: 0x2800)
Slot 1 - PCI device: serial bus controller
(Bus: 0, Device: 10, Function: 2)
(Subs. Vendor: 0x5444, Subs. Device: 0x2800)
Current production date: 07 47
Current software license: 16 12
Teldat H/L Router Family
Nov 22 2007 10:11:53
Microcode:00E1
BUSCLK=65536 KHz PCICLK=32768 KHz
Time: 18:40:04
Write-Back
L0
