SPECIFICATIONS AND OPTIONS
■ Specifications
GENERAL
• Frequency coverage
Receive
500 kHz–29.999 MHz
Transmit
1.6– 2.9999 MHz
6.0– 6.9999 MHz
12.0– 13.9999 MHz
18.0– 19.9999 MHz
25.0– 27.5000 MHz
• Mode
• Number of channels
• Antenna impedance
• Usable temp. range
• Frequency stability
• Power supply requirement : 13.6 V DC±15%
• Current drain
Transmit
(max. output power)
Receive
(max. audio output)
• Dimensions
(projections not included)
• Weight (approx.)
■ Options
MN-100
antenna matcher
Matches the transceiver to a
dipole antenna. Covers all HF
bands from 1.5 to 30 MHz.
8 m (26 ft.) × 2 antenna wires
are included.
AT-130
automatic antenna tuner
Matches the transceiver to a
long wire antenna with a mini-
mum of insertion loss.
23
:
4.0– 4.9999 MHz
8.0– 8.9000 MHz
16.0– 17.9999 MHz
22.0– 22.9999 MHz
: USB, AM, CW, FSK and AFSK
(
available modes differ with the
version)
: 150 channels (max.)
3 groups of 50 channels each
: 50 ø nominal
: –30°C to +60°C
(–22°F to +140°F)
: ±10 Hz
(–30°C to +60°C; –22°F to +140°F)
( ±20 Hz above 15 MHz for Gen-
eral and Marine versions)
( negative and floating grounds
available depending on the ver-
sion)
:
30 A
2.5 A
(negative ground)
: 291.4(W)×116.4(H)×315(D) mm
11.3(W)×4.4(H)×12.8(D) in
: 7.9 kg; 17.4 lb
MN-100L
antenna matcher
Matches the transceiver to a
long wire antenna. Covers all
HF bands from 1.5 to 30 MHz.
15 m (49 ft.) × 1 antenna wire
are included.
OPC-566
control cable
The optional control cable for
AT-130.
TRANSMITTER
• Output power
• Spurious emissions
• Carrier suppression
• Unwanted sideband suppression : 70 dB
• Microphone impedance
RECEIVER
• Sensitivity
USB, CW, AFSK, FSK,
0.35 µV
typical (1.8–29.9999 MHz)
1.0 µV
(1.6–1.7999 MHz)
6.3 µV
(0.5–1.5999 MHz)
AM
:
(for 10 dB S/N)
2.2 µV
typical (1.8–29.9999 MHz)
6.3 µV
(1.6–1.7999 MHz)
32 µV
(0.5–1.5999 MHz)
• Spurious response rejection
• Audio output power
• Audio impedance
• Clarity variable range
All stated specifications are subject to change without no-
tice or obligation.
AH-710
folded dipole antenna
Covers from 1.9 to 30 MHz
band. Has an SO-239 con-
nector. Easy to assemble
(non-kink construction).
Approved Icom optional equipment is designed for optimal
performance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to an
Icom transceiver in the event the Icom transceiver is used
with equipment that is not manufactured or approved by
Icom.
: 150 W
pep
(60 W above 24 MHz)
: –75 dB
typical
: 65 dB
typical
typical
: 600 ø
:
(for 12 dB SINAD)
: 80 dB
typical
(1.6–29.9999 MHz)
: 4.0 W
(at 10% distortion
ø
with a 4
load)
: 4 ø
(4 to 8 ø acceptable)
: ±150 Hz
