INSTRUCTION MANUAL
SSB RADIO TELEPHONE
iM700PRO

Advertisement

Table of Contents
loading

Related Manuals for Icom IC-M700PRO

Summary of Contents for Icom IC-M700PRO

  • Page 1 INSTRUCTION MANUAL SSB RADIO TELEPHONE iM700PRO...

  • Page 2: Important

    NEVER expose the transceiver to rain, snow or any liquids. NEVER install the IC-M700PRO into a plus-grounding ship. Such a connection might blow fuses and is not usable. DO NOT use chemical agents such as benzene or al- cohol when cleaning, as they can damage the trans- ceiver’s surfaces.

  • Page 3: Versions

    Push [ALARM] to turn the alarm transmission off, then push and hold the PTT switch on the micro- phone and send the following information: VERSIONS The following versions are available for the IC-M700PRO. Version Description 2182 kHz 2-tone alarm is built-in. Marine FSK/CW narrow filter is optional.

  • Page 4: Table Of Contents

    D AT-130 ....... . . 19 D Non-Icom tuner ......19 I Mounting .

  • Page 5: Operating Rules And Guidelines

    OPERATING RULES AND GUIDELINES ❑ CALL PROCEDURES Calls must be properly identified and time limits must be respected. ➀ Give your call sign each time you call another vessel or coast station. If you have no call sign, identify your vessel name and the name of the licensee. ➁...

  • Page 6: Panel Description

    ANTENNA TUNE SWITCH [TUNE] (p. 8) Tunes the connected tuner to the antenna. • Activates only when an optional antenna tuner such as Icom’s AT-130 is connected. NOTE: When selecting “automatic tuning” in set mode, pushing this switch is not necessary to tune the antenna.
  • Page 7 !1 KEYPAD No function*. Toggles between memory mode and VFO CH/FREQ mode. (p. 5) • This key may be disabled by your dealer. No function*. T ONLY No function*. No function*. !2 SQUELCH SWITCH [SQL] (p. 9) Activates the voice squelch function to reject unde- sired background noise while no signal is being re- ceived.

  • Page 8: I Display

    Appears while receiving and when the squelch is open. e TUNE INDICATOR (p. 8) Flashes while the connected antenna tuner, such as Icom’s AT-130, is being tuned. • Tuning starts when transmitting on a new frequency or pushing the [TUNE] switch. r TRANSMIT INDICATOR Appears when transmitting.

  • Page 9: Selecting A Channel/Frequency

    SELECTING A CHANNEL/FREQUENCY I Memory mode/VFO mode The transceiver has 2 operating modes: memory mode and VFO mode. Memory mode is used to select pre- programmed marine channels in one of the 3 channel groups; VFO mode is used to select frequencies around preprogrammed channels.

  • Page 10: D Scan Function

    SELECTING A CHANNEL D Scan function The scan function allows you to automatically search channels within a group for signals. There are 2 scan types (selectable in set mode) as follows: Channel scan ch 2 ch 3 ch 1 ch 50 ch 5 Channel resume scan ch 2...

  • Page 11: I Resetting The Cpu

    I Resetting the CPU Under some circumstances the transceiver’s internal CPU may cause erroneous indications on the display. If this happens, reset the CPU as follows: While pushing [ENT] + [0], push [POWER] to turn power on. • The CPU is reset and the display at right appears. CAUTION: Resetting the CPU returns set mode contents to their default values.

  • Page 12: Receive And Transmit

    RECEIVE AND TRANSMIT I Basic voice receive and transmit ➀ Check the following in advance: ➥ Microphone is connected. ➥ [SPEAKER] switch is turned off. ➥ [SQL] switch is turned off. ➥ [CLARITY] control is set to the center position. ➥...

  • Page 13: I Functions For Receive

    I Functions for receive D Squelch function The squelch function detects signals with voice com- ponents and squelches (mutes) unwanted signals such as unmodulated beat signals. This provides quiet standby. When you need to receive weak signals, the squelch should be turned off. D Noise blanker The noise blanker function reduces pulse type noise such as that coming from engine ignitions.

  • Page 14: I Cw Operation

    ➥ FSK shift frequency and FSK polarity can be adjusted in set mode (p. 12). ➥ Some transceivers my operate 1.7 kHz higher than the IC-M700PRO’s J2B mode even when the same displayed frequencies are in use. CW key connection...

  • Page 15: Set Mode

    I Set mode contents (1) Connected antenna tuner The transceiver has several tuner control systems for use with an optional Icom antenna tuner. Select the condition depending on the connected antenna tuner. NOTE: Internal switch selection may be required when using a non-Icom tuner (p. 19).
  • Page 16 SET MODE (4) Scan speed Selects scan speed as follows: Faster (5) CW/FSK narrow filter This item selects the passband width for CW (A1A), FSK or J2B mode. ✍ NOTE: When “on” is selected without optional fil- ter installation, the transceiver does not function in these modes.
  • Page 17 (10) ID number setting for remote control When connecting an external controller such as a personal computer, 2-digit ID codes are required to access the transceiver. The IC-M700PRO adopts NMEA0183 format and uses a “proprietary sentence” for remote control. (11) Remote control input terminal Remote control signals can be input via the [RE- MOTE] socket or [CLONE] jack.
  • Page 18 SET MODE (14) Group B channel inhibit This item allow you to set the number of usable chan- nels in channel group B, up to a maximum of 50 channels. (15) Group C channel inhibit This item allow you to set the number of usable chan- nels in channel group C, up to a maximum of 50 channels.

  • Page 19: Connections And Installation

    CONNECTIONS AND INSTALLATION I Connections on rear panel Optional AT-130 q ANTENNA CONNECTOR (p. 19) Connects a 50 Ω HF band antenna with a 50 Ω matched coaxial cable and a PL-259 plug. w GROUND TERMINAL IMPORTANT! Connects a ship’s (or vehicle’s) ground.

  • Page 20: I Connector Information

    CONNECTIONS AND INSTALLATION I Connector information ACC(1) PIN PIN NAME SEND 13.6 V ACC(2) PIN PIN NAME SEND 13.6 V MICROPHONE PIN NAME MIC+ MIC– AF– TUNER PIN NAME START 13.6V ANTC DESCRIPTION CW and FSK keying input. Connects to ground. Input/output pin.
  • Page 21 REMOTE PIN PIN NAME Modulation input from an external MOD+ terminal unit. MOD– Coaxial ground for MOD+. AF detector output for an external terminal unit. AF– Coaxial ground for AF+. NMI+ NMEA data input. NMI– Coaxial ground for NMI+. NMO+ NMEA data output.

  • Page 22: I Ground Connection

    Ground the transceiver and antenna tuner to one ground point, otherwise voltage differences between 2 ground points may cause electrolysis. R CAUTION: The IC-M700PRO has a negative ground. NEVER connect the IC-M700PRO to a “plus-grounding ship,” otherwise the transceiver will not function.

  • Page 23: I Antenna

    START 13.6 Coaxial cable D Non-Icom tuner Some non-Icom tuners may be used with the IC- M700PRO. Please consult your dealer or marina if you wish to connect one. The following internal set- tings may be required for connection. Supplies 8 V when push- ing [TUNE].

  • Page 24: I Mounting

    CONNECTIONS AND INSTALLATION I Mounting R WARNING: NEVER mount the transceiver over- head. The weight of the transceiver is approximately 8 kg., but its apparent weight will increase several fold due to wave shocks or vibration. The trans- ceiver must be mounted on a flat, hard surface. D Mounting example D Transceiver dimensions 319 (12...

  • Page 25: I Installing Internal Options

    D Opening the case Follow the case and cover opening procedures shown here when you want to install an option or ad- just a setting for non-Icom tuner control. ➀ Remove the 9 screws from the rear panel, then re- move the rear frame and rear sealing.

  • Page 26: Troubleshooting

    What appears to be equipment malfunction may not be damaging or difficult to solve. Check the following chart before making any adjustments or sending the trans- ceiver to an Icom Service Center. PROBLEM Power does not come on when [POWER] is pushed.

  • Page 27: Specifications And Options

    SPECIFICATIONS AND OPTIONS I Specifications GENERAL • Frequency coverage: Receive 500 kHz–29.999 MHz Transmit 1.6– 2.9999 MHz 6.0– 6.9999 MHz 12.0– 13.9999 MHz 16.0–17.9999 MHz 18.0– 19.9999 MHz 22.0–22.9999 MHz 25.0– 27.5000 MHz • Mode: USB, AM, CW, FSK and AFSK available modes differ with version) •...
  • Page 28 Count on us! A-5472H-1EX Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan Copyright 1997 by Icom Inc.
