E-Series HMI
W07FA3S-EHT1
W10FA3S-EHH2
W15FA3S-EHA2
Quick Start Guide
V1.1
For more information on this and other Winmate
products, please visit our website at:
www.winmate.com
Document Part Number: 9152111I101C
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W07FA3S-EHT1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate W07FA3S-EHT1

Summary of Contents for Winmate W07FA3S-EHT1

  • Page 1 W10FA3S-EHH2 W15FA3S-EHA2 Quick Start Guide V1.1 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111I101C Please read these instructions carefully before using this product, and save this manual for future use.
  • Page 2 Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability for the...

  • Page 3: Table Of Contents

    Changing Serial Port Settings Operating the HMI Device Ethernet Main Menu Configuring Ethernet Checking Ethernet Settings Winmate® Home Manager How to Lock Applications How to Reset WHM Please read these instructions carefully before using this product, and save this manual for future use.
  • Page 4 Software Developer Support Winmate Software Development Kit Winmate Download Center Winmate File Share Technical Specifications HMI Device Specifications...

  • Page 5: Getting Started

    Getting Started Congratulations on purchasing Winmate® E-Series HMI. Winmate® continues developing new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). Our E-Series HMI runs on Android 4.4 / Linux operating system that allows installing the latest applications (APPs). Thereby wide customization possibilities are available to satisfy the needs of industrial automation.

  • Page 6: Unpacking

    Unpacking Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Accessories Standard factory shipment list: Quick Start Guide 7”...

  • Page 7: Description Of Parts

    Description of Parts E-Series HMI 7” ① Mini USB Console (Linux use) ⑤ RS232/422/485 ② Micro SD ⑥ CAN BUS ③ LAN/ PoE ⑦ 1 x USB 2.0 ④ USB OTG ⑧ 12V DC in (Phoenix type) Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 8: E-Series Hmi 10.1

    E-Series HMI 10.1” ① Mini USB Console (Linux use) ⑤ RS232/422/485 ② Micro SD ⑥ CAN BUS ③ LAN/ PoE ⑦ 1 x USB 2.0 ④ USB OTG ⑧ 12V DC in (Phoenix type) E-Series HMI 15.6” ① Mini USB Console (Linux use) ⑤...

  • Page 9: Dimensions 7

    Dimensions Dimensions 7” Dimensions 10.1” Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 10: Dimensions 15.6

    Dimensions 15.6” Note: this is a simplified drawing and some components are not marked in detail.

  • Page 11: Mounting

    Mounting VESA Mount (only for 7” E-Series HMI) VESA Mount is a widely used mounting solution suitable for all kinds of applications. Dimensions Screw Hole Diameter 75 x 75 mm VESA M4 x 3 mm *with customer’s bracket Mounting Steps: 1.

  • Page 12: Panel Mount

    Panel Mount In addition to elegant design, panel mount solution is making the HMI unit easy to clean and maintain. The HMI device is secured to the fixture from the rear by using the mounting brackets included in the package. Cutout dimension ( W x D in mm) 7”...

  • Page 13: Connector Description

    TxD- TxD+ RxD+ RxD- Serial port settings can be configured in Winmate application for Android OS. “Configuring Serial Port Settings” of this Quick Start Guide for more detail. Refer to Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 14: Lan (Rj45) Connector

    LAN (RJ45) Connector The E-Series HMI supports one 10/100/1000 Mbps Ethernet interface for connecting to the internet. Pin № Pin № Name Name TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- USB A Type Connector Use USB A Type (USB2.0) connector to connect your HMI device to other USB2.0 compatible devices.

  • Page 15: Can Bus Connector

    CAN BUS Connector Use CAN BUS connector for the HMI machine-to-machine communication. Pin № Pin № Name Name CAN_L CAN_H +5V/NC *PIN9 default is NC Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 16: Turning On Or Off

    Turning ON or OFF Turning ON Follow the following steps to turn on your HMI device: 1. Connect a 3-pin terminal block to the HMI connector. 2. Connect the other side of the terminal block to the AC adapter. 3. Connect the AC adapter to the power cord. 4.

  • Page 17: Changing Serial Port Settings

    Changing Serial Port Settings Serial port can be configured for RS-232, RS-422 or RS-485. Winmate® provides serial port settings application for Android OS. To configure serial port settings follow the instructions below: Step 1 Settings > Accessibility Step 2 Accessibility > Comport-Setting...
  • Page 18 Step 3 Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. Step 4 Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings...

  • Page 19: Operating The Hmi Device

    Operating the HMI Device This section explains how to adjust main system settings in Android 4.4. Ethernet Main Menu Use Android application to connect Ethernet. Step 1 Connect Ethernet Cable to the HMI device. Step 2 Go to APPS. Open Ethernet application.

  • Page 20: Configuring Ethernet

    Configuring Ethernet Go to Apps > Ethernet > Configure Ethernet *Ethernet OFF is set by default. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP (default) The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway...

  • Page 21: Checking Ethernet Settings

    Checking Ethernet Settings Go to APPS > Ethernet > Check Ethernet Ethernet settings menu appears on the top right side of the desktop. For a more detailed Android 4.4 user guide, follow the download path below: http://static.googleusercontent.com/media/www.google.com/en/us/help/hc/images/android/and roid_ug_42/Android-Quick-Start-Guide.pdf Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 22: Winmate® Home Manager

    Winmate® Home Manager Winmate ® E-Series HMI comes with preinstalled APP named Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. How to Lock Applications Step 1 In the main APPS window, select the Home Manager APP tap it to open.
  • Page 23 Step 3 Go back to “Home Selector” and press “Clear and Reset Default Home”. Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 24: How To Reset Whm

    Step 4 Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it. Whatever you press home key or back key; the system will go back to the same application which you have selected.
  • Page 25 Step 2 System will request the password to login. Default password is “0000”. Step 3 Restart the system and you will go back to the normal Launcher. Please read these instructions carefully before using this product, and save this guide for future use.

  • Page 26: Software Developer Support

    Software Developer Support Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for E-Series HMI with Freescale® Cortex® A9 i.MX6 Dual Core processor: Item Driver Description Android Driver USB Driver Android Driver...

  • Page 27: Technical Specifications

    Technical Specifications HMI Device Specifications Model Name W07FA3S-EHT1 W10FA3S-EHH2 W15FA3S-EHA2 Display 7” TFT 10.1” TFT Size/ Type 15.6" TFT Resolution 1024x600 1280 x 800 1366 x 768 Brightness 320cd/m (typ.) 350 cd/m (typ.) 400 cd/m (typ.) Contrast Ratio 500 : 1 (typ.) 800:1 (typ.)
  • Page 28 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
