G-WIN Slim IP65
P-CAP Panel PC
W07FA3S-GSM1(HB)
W10FA3S-GSH2
W10FA3S-GSH1(HB)
R12FA3S-GSM2(HB)
R15FA3S-GSC3(HB)
Quick Start Guide
V1.0
For more information on this and other Winmate
products, please visit our website at:
www.winmate.com
Document Part Number: 91521110100O
Please read these instructions carefully before using this product, and save this manual for future use.
Advertisement
Table of Contents
Related Manuals for Winmate W07FA3S-GSM1
Summary of Contents for Winmate W07FA3S-GSM1
- Page 1 R12FA3S-GSM2(HB) R15FA3S-GSC3(HB) Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 91521110100O Please read these instructions carefully before using this product, and save this manual for future use.
-
Page 2: Fcc Statement
FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"... - Page 3 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability...
- Page 4 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may need the following information ready before you call: ...
-
Page 5: Table Of Contents
Connecting to Other Devices Connector Description Power Input Connector Serial Interface Connector Giga LAN + USB 2.0 Connector USB OTG Connector MicroSD Card Mounting VESA Mounting Panel Mounting SPECIFICATIONS Hardware Specifications APPENDIX Appendix A: Cleaning the Monitor Appendix B: Winmate Software Development Kit... -
Page 7: Introduction
INTRODUCTION Congratulations on purchasing Winmate® G-WIN Slim IP65 with P-CAP Panel PC. The elegantly designed, yet rugged, industrial grade G-WIN S65 series is designed for usability with brilliant true-flat screens, which offer superior readability and Projected Capacitive Multi-Touch (P-CAP) technology, available in 7”, 10.1”, 12.1”... -
Page 8: Package Contents
Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start Guide Driver CD &... -
Page 9: Description Of Parts
Description of Parts W07FA3S-GSM1(HB) Unit: mm Dimensions: 189.4 x 145.4 x 39.8 № № Description Description ① ④ 9-24V DC (M12 Type) USB OTG, Console Port, MicroSD ② ⑤ LAN, USB (M12 Type) 1 Watt Speaker ③ RS232 (M12 Type) - Page 10 W10FA3S-GSH2, W10FA3S-GSH1(HB) Unit: mm Dimensions: 263.28 x 173.6 x 40.2 № № Description Description ① ④ 9-24V DC (M12 Type) USB OTG, Console Port, MicroSD ② ⑤ LAN, USB (M12 Type) 1 Watt Speaker ③ RS232 (M12 Type)
- Page 11 R12FA3S-GSM2(HB) Unit: mm Dimensions: 296.2 x 226.7 x 45.5 № № Description Description ① ④ 9-24V DC (M12 Type) USB OTG, Console Port, MicroSD ② ⑤ LAN, USB (M12 Type) 1 Watt Speaker ③ RS232 (M12 Type)
- Page 12 R15FA3S-GSC3(HB) Unit: mm Dimensions: 363.4 x 277.86 x 45.2 № № Description Description ① ④ 9-24V DC (M12 Type) USB OTG, Console Port, MicroSD ② ⑤ LAN, USB (M12 Type) 1 Watt Speaker ③ RS232 (M12 Type)
-
Page 13: Getting Started
GETTING STARTED Turning On Your Device 1. Remove the protective cap of the power connector. 2. Connect power cable to the connector of your device. Make sure the cable fits to the connector, then tighten the O-ring (by turning clockwise) to secure the connection. -
Page 14: Configuring Serial Port Settings
Configuring Serial Port Settings Serial COM Port can be configured for RS-232, RS-422 or RS-485. Winmate provide COM port settings application for Android OS. To configure serial port settings: 1. Go to Settings > Accessibility. 2. Go to Accessibility > Comport-Setting. - Page 15 3. Go to Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. 4. In COM port settings select Comport 1 > RS232/RS422/RS485 *This example shows how to configure Comport 1 settings...
-
Page 16: Brightness Adjustment
Brightness Adjustment Use can adjust the screen brightness in Android settings. Pull down from the top of the screen to get the notifications area. You can also access display settings in the settings menu. To adjust the brightness of the screen: Go to Settings >... -
Page 17: Operating The Device
Operating the Device Winmate® G-WIN Slim IP65 with P-CAP Panel PC.runs on Android 4.4 OS (Default). Setting up the Device When you first turn on your device, you will see a Welcome screen. Choose the language you want and touch Start or the Start icon. When prompted, you can sign in with your Google Account to create one at that time. -
Page 18: Quick Settings
Quick Settings To open Settings, Swipe down from the top right of the screen and touch the Settings icon. You can open your device’s Settings app from the All Apps screen or from Quick Settings. For example, to change notification sounds, and volume go to Settings >... -
Page 19: Ethernet
Ethernet 1. Connect Ethernet Cable to the device. 2. Go to APPS > Ethernet 3. Ethernet APP main menu appears Setting Description Check Ethernet connection parameters: IP mode, IP Check Ethernet address, DNS address and others Enable Ethernet connection and configure its such Configure Ethernet as connection type Advanced Settings... -
Page 20: Configuring Ethernet
Configuring Ethernet To configure Ethernet settings go to Apps > Ethernet > Configure Ethernet. Default settings: Ethernet OFF. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway Configuring Ethernet... -
Page 21: Winmate® Home Manager (Whm)
Winmate® Home Manager (WHM) Winmate® Panel PC running on Android OS comes with preinstalled APP named Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. - Page 22 Home Manager booting. Set the WHM password. Password Manager (Default password is “0000”) Displays information about Winmate® Home About Manager. 2. Go to “Application Selector”, and choose the app which you want to run up automatically after booting. 3. Go back to “Home Selector” and press “Clear and Reset Default Home”.
- Page 23 4. Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it. Any time user press home key or back key, the system will go back to the same application which you have selected.
-
Page 24: How To Unlock Applications
How to Unlock Applications Follow the instruction below to reset WHM. 1. If you want to reset the home manager, pull down the left side to open the status bar and open HomeManager service. 2. System will request the password to login. Default password is “0000”. -
Page 25: How To Change Password
3. Restart the system and you will go back to the normal Launcher. How to Change Password To change the password: 1. Go to Password Manager and set your own password for this APP. 2. The default password is “0000”. Enter a new password in New Password field, and then tap Change Password. -
Page 26: Installation
INSTALLATION Wiring Requirements The following common safety precautions should be observed before installing any electronic device: Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. ... -
Page 27: Connecting To Other Devices
Connecting to Other Devices This Panel PC comes with various interfaces located on the bottom panel. All of these connectors have been shipped with protective caps. To ensure the waterproof function can work properly, make sure that the protective caps and have been securely tightened whenever the connectors are not used. -
Page 28: Connector Description
Connector Description The Panel PC features M12 type connectors with protective cap and has full IP65 rating. Power Input Connector Panel PC has M12 type 3 pin male power input connector which accepts 9~24V DC power input. Use IP65 power cable to connect the Panel PC to the source of power. -
Page 29: Serial Interface Connector
Serial Interface Connector Panel PC has M12 type 10 pin male RS-232 connector. Use IP65 serial cable to connect the Panel PC to external devices. -
Page 30: Giga Lan + Usb 2.0 Connector
Giga LAN + USB 2.0 Connector Panel PC has M12 type 12 pin male Giga LAN and USB connector that supports two LAN and one USB 2.0. -
Page 31: Usb Otg Connector
USB OTG Connector Panel PC has USB OTG connector located either on the rear side or on the bottom. Use USB OTG connector to connect the Panel PC to other USB On- The-Go compliant devices such as flash drives, digital cameras, mice or keyboards. -
Page 32: Mounting
75x75 mm 15” 100x100 mm Mounting Instruction Use Philips M4x5 screws to fix the desk stand to VESA holes on the back cover of the device. *The picture is for demonstration purposes only. VESA Mounting accessories are not supplied by Winmate. -
Page 33: Panel Mounting
Panel Mounting Panel Mount mounting solutions is suitable for many applications where Panel PC should be embedded. With this mounting solution flat surface leave no bezel in the front. Size Wall Cutout, mm Screw Hole Diameter, mm 7” 174.4 x 130.4 M4x4 10.1”... -
Page 34: Specifications
SPECIFICATIONS Hardware Specifications Model Name W07FA3S- W10FA3S- W10FA3S- R12FA3S- R15FA3S- GSM1(HB) GSH2 GSH1(HB) GSM2(HB) GSC3(HB) Display 10.1” TFT 10.1” TFT 7" TFT 12.1” TFT 15” TFT Size/Type (Wide) (Wide) (Wide) Resolution 1024 x 600 1280 x 800 1024 x 600 1024 x 768 1024 x 768 500 nits 200 nits... - Page 35 Input/ Output COM Port 1 x RS232/422/485 (M12 Type) USB Port 1 x USB 2.0 (M12 Type), 1 x USB OTG (On side) Ethernet 1 x 10/100/100 LAN (M12 Type) Speaker 1 x 1 Watt Speaker SD Slot MicroSD Card Slot Power Specifications Power Input 9~24V DC...
-
Page 36: Appendix
APPENDIX Appendix A: Cleaning the Monitor Before cleaning: Make sure the device is turned off. Disconnect the power cable from any AC outlet. When cleaning: Never spray or pour any liquid directly on the screen or case. ... -
Page 37: Appendix B: Winmate Software Development Kit
Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for Winmate® G-WIN Slim IP65 with P-CAP Panel PC with Freescale® Cortex® A9 processor: Item File Type Description Android Driver Programming Guide... - Page 38 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________...
- Page 39 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________...
- Page 40 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
