Winmate W04FA3S-EHT1 Quick Start Manual

E-series hmi freescale cortex a9 i.mx6 dual core 1 ghz
Hide thumbs Also See for W04FA3S-EHT1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Quick Start Manual
Freescale Cortex A9 i.MX6 Dual Core 1 GHz
Quick Start Guide
For more information on this
and other Winmate products,
please visit our website at:
www.winmate.com
Document Part Number: 9152111I101C
Android 6.0
Please read these instructions carefully before using this product, and save this manual for future use
E-Series HMI
W04FA3S-EHT1
W07FA3S-EHT1
W10FA3S-EHH2
W15FA3S-EHA2
V1.4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W04FA3S-EHT1 and is the answer not in the manual?

Questions and answers

Related Manuals for Winmate W04FA3S-EHT1

Summary of Contents for Winmate W04FA3S-EHT1

  • Page 1 W10FA3S-EHH2 W15FA3S-EHA2 Quick Start Guide V1.4 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111I101C Android 6.0 Please read these instructions carefully before using this product, and save this manual for future use...

  • Page 2: Table Of Contents

    3.2.2 Panel Mounting ......................- 31 - 4 SPECIFICATIONS ..............- 32 - 4.1 Hardware Specifications - 32 - APPENDIX .................. - 34 - Appendix A: Cleaning the Monitor - 34 - Appendix B: Winmate Software Development Kit - 35 - - 2 -...
  • Page 3 FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received  including interference that may cause undesired operation.
  • Page 4 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance.
  • Page 5 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
  • Page 6 Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis.

  • Page 7: Introduction

    1 INTRODUCTION Congratulations on purchasing Winmate® E-Series HMI. Winmate® continues developing new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). Our E-Series HMI runs on Android 6.0 / Linux operating system that allows installing the latest applications (APPs).

  • Page 8: Package Contents

    1.2 Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start User Manual USB to Micro HMI Device...

  • Page 9: Product Overview

    1.3 Product Overview 1.3.1 E-Series HMI 4.3” Unit: mm № Description № Description ① USB OTG ④ LAN/ Optional PoE 12-24V DC in ② USB 2.0 ⑤ (Power jack) ③ RS485 - 9 -...

  • Page 10: E-Series Hmi 15.6

    1.3.2 E-Series HMI 7” Unit: mm № Description № Description Mini USB Console ① ⑥ CANBUS (Linux use) ② Micro SD ⑦ Micro HDMI ③ LAN/ Optional PoE ⑧ USB 2.0 ④ USB OTG ⑨ 12V DC in (Phoenix type) ⑤...
  • Page 11 1.3.3 E-Series HMI 10.1” Unit: mm № Description № Description Mini USB Console ① ⑥ CANBUS (Linux use) ② Micro SD ⑦ Micro HDMI ③ LAN/ Optional PoE ⑧ USB 2.0 ④ USB OTG ⑨ 12V DC in (Phoenix type) ⑤...

  • Page 12: E-Series Hmi 15.6

    1.3.4 E-Series HMI 15.6” Unit: mm № Description № Description Mini USB Console ① ⑥ CANBUS (Linux use) ② Micro SD ⑦ Micro HDMI ③ LAN/ Optional PoE ⑧ USB 2.0 ④ USB OTG ⑨ 12V DC in (Phoenix type) ⑤...

  • Page 13: Getting Started

    2 GETTING STARTED 2.1 Turning on Your Device Follow the following steps to turn on your HMI device: 1. Connect a 2-pin terminal block to the HMI connector. 2. Connect the other side of the terminal block to the AC adapter. 3.

  • Page 14: Connecting To Other Devices

    RS-232/422/485 Pin № RS-232 RS-422 RS-485 (Default) TxD- TxD+ RxD+ Serial port settings can RxD- be configured in Winmate application for Android OS. Refer to “Configuring Serial Port Settings” of this Quick Start Guide for more details. - 14 -...

  • Page 15: Lan (Rj45) Connector

    RS-485 Pin № RS-485 2.2.3 LAN (RJ45) Connector The E-Series HMI supports one 10/100/1000 Mbps Ethernet interface for connecting to the internet. Pin № Signal Signal Name № Name TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- IMPORTANT: Supports PoE (Optional). Power Device (PD) follows IEEE 802.3at (25W).

  • Page 16: Micro Hdmi Connector

    2.2.4 Micro HDMI Connector The E-Series HMI has one Micro HDMI connector. Pin № Pin № Signal Name Signal Name HP_DET_OUT HDMI_D2P HDMI_D2M HDMI_D1P HDMI_D1M HDMI_D0P HDMI_D0M HDMI_CLKP HDMI_CLKM HDMI_CEC_O H_CLK_OUT H_DAT_OUT HDMI_5V 2.2.5 USB A Type Connector Use USB A Type (USB2.0) connector to connect your HMI device to other USB2.0 compatible devices.

  • Page 17: Usb Otg Connector

    2.2.6 USB OTG Connector Use USB OTG connector to connect the HMI device to other external devices. Use USB OTG cable to install software on the HMI device. Pin № Pin № Signal Name Signal Name USB_OTG_D Refer to the E- USB_OTG_D USB_OTG_ID Series HMI User...

  • Page 18: Changing Serial Port Settings

    2.3 Changing Serial Port Settings Serial COM Port can be configured for RS-232, RS-422 or RS-485. Winmate provide COM port settings application for Android OS. To configure serial port settings: 1. Settings > Accessibility. 2. Accessibility > System: Comport-Setting. - 18 -...
  • Page 19 3. Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. 4. Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings - 19 -...

  • Page 20: Ethernet

    2.4 Ethernet 2.4.1 Main Menu 1. Connect Ethernet Cable to the HMI. 2. Touch All APPS icon, and the open Ethernet application. 3. Ethernet APP main menu appears Setting Description Check Ethernet connection parameters: IP Check Ethernet mode, IP address, DNS address and others Configure Enable Ethernet connection and configure Ethernet...

  • Page 21: Configuring Ethernet

    2.4.2 Configuring Ethernet Go to All Apps > Ethernet > Configure Ethernet *Ethernet OFF is set by default. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description DHCP The device automatically capture IP-address from the router Static IP Allows to manually set up IP-address, DNS, Network and Gateway - 21 -...

  • Page 22: Checking Ethernet Settings

    2.4.3 Checking Ethernet Settings To check Ethernet settings: Go to All Apps > Ethernet > Check Ethernet Ethernet settings menu appears on the top right side of the desktop. - 22 -...

  • Page 23: Winmate® Home Manager

    2.5 Winmate® Home Manager Winmate ® E-Series HMI comes with preinstalled APP named Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. 2.5.1 How to Lock Applications To lock applications: 1.
  • Page 24 Menu Description Set which app you want to run up automatically Home Manager after booting Password Set the WHM password (Default password is “0000”). Manager About Displays information about Home Manager 2. Go to “Application Selector”, and choose the app which you want to run up automatically after booting.
  • Page 25 3. Go back to “Home Selector” and press “Clear and Reset Default Home”. 4. Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock it. Any time user presses home key or back key; the system will go back to the same application which you have selected.

  • Page 26: How To Unlock Application

    2.5.2 How to Unlock Application Follow the instruction below to reset Home Manager. 1. If you want to reset the home manager, pull down the left side to open the status bar and open HomeManager. 2. System will request the password to login. Touch OK. - 26 -...

  • Page 27: How To Change Password

    Default password is “0000”. 3. Restart the system and you will go back to the normal Launcher. 2.5.3 How to Change Password To change the password: 1. Go to Password Manager and set your own password for this APP. 2. The default password is “0000”. Enter a new password in New Password field, and then tap Change Password.

  • Page 28: Turning Off Your Device

    2.6 Turning off Your Device Disconnect the power cord from the HMI device to completely turn off the device. - 28 -...

  • Page 29: Installation

    3 INSTALLATION 3.1 Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point.

  • Page 30: Mounting Solution

    3.2 Mounting Solution 3.2.1 VESA Mounting VESA Mount is a widely used mounting solution suitable for all kinds of industrial applications. Notice that VESA mounting solution applies only to 7” E-Series HMI. Mounting Instruction: 1. Screw VESA bracket to the fixture (ex. wall) with four M4 x 3 mm VESA screws.

  • Page 31: Panel Mounting

    3.2.2 Panel Mounting In addition to elegant design, panel mount solution is making the HMI unit easy to clean and maintain. The HMI device is secured to the fixture from the rear by using the mounting brackets included in the package.

  • Page 32: Specifications

    4 SPECIFICATIONS 4.1 Hardware Specifications Model Name W04FA3S- W07FA3S- W10FA3S- W15FA3S- EHT1 EHT1 EHH2 EHA2 Display 4.3” TFT 7” TFT 10.1” TFT 15.6" TFT Size/ Type (Widescreen) (Widescreen) (Widescreen) (Widescreen) Resolution 480 x 272 1024x600 1280 x 800 1366 x 768 350 cd/m 400 cd/m Brightness...
  • Page 33 1 x RJ45, 10/100/1000 1 x RJ45, 10/100/1000 LAN Ethernet LAN (Optional (Optional PoE function) PoE function) MicroSD Card SD Slot Micro SD Card Slot Slot Console Mini USB Console (for Linux use) HDMI Micro HDMI Power Specifications Power Input 12-24V DC in 9-24V DC in 12V DC in...

  • Page 34: Appendix

    APPENDIX Appendix A: Cleaning the Monitor Before cleaning:  Make sure the device is turned off.  Disconnect the power cable from any AC outlet. When cleaning:  Never spray or pour any liquid directly on the screen or case. ...

  • Page 35: Appendix B: Winmate Software Development Kit

    Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for E-Series HMI with Freescale® Cortex® A9 i.MX6 Dual Core processor: Item File Type Description Android Driver USB Driver Android Driver...
  • Page 36 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
