Winmate W07FA3S-EHT1 Quick Start Manual

E-series hmi
Hide thumbs Also See for W07FA3S-EHT1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
E-Series HMI
W07FA3S-EHT1
W10FA3S-EHH2
W15FA3S-EHA2
Quick Start Guide
V1.1
For more information on this and other Winmate
products, please visit our website at:
www.winmate.com
Document Part Number: 9152111I101C
Please read these instructions carefully before using this product, and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W07FA3S-EHT1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Winmate W07FA3S-EHT1

Summary of Contents for Winmate W07FA3S-EHT1

  • Page 1 W10FA3S-EHH2 W15FA3S-EHA2 Quick Start Guide V1.1 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 9152111I101C Please read these instructions carefully before using this product, and save this manual for future use.

  • Page 2: Fcc Statement

    FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference.  This device must accept any interference received  including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "B"...
  • Page 3 Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserve the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume no responsibility or liability...
  • Page 4 Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may need the following information ready before you call: ...

  • Page 5: Table Of Contents

    Checking Ethernet Settings Winmate® Home Manager How to Lock Applications How to Reset WHM Turning Off Your Device INSTALLATION Wiring Requirements Mounting Solution VESA Mounting Panel Mounting SPECIFICATIONS Hardware Specifications APPENDIX Appendix A: Cleaning the Monitor Appendix B: Winmate Software Development Kit...

  • Page 7: Introduction

    INTRODUCTION Congratulations on purchasing Winmate® E-Series HMI. Winmate® continues developing new generation of Human Machine Interfaces for Industry 4.0 and Internet of Things (IoT). Our E-Series HMI runs on Android 4.4 / Linux operating system that allows installing the latest applications (APPs). Thereby wide customization possibilities are available to satisfy the needs of industrial automation.

  • Page 8: Package Contents

    Package Contents Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: Quick Start User Manual USB to Micro HMI Device...

  • Page 9: Product Overview

    Product Overview E-Series HMI 7” Unit: mm Dimensions: 184.8 x 128.6 x 50.2 mm № Description № Description ① Mini USB Console (Linux use) ⑤ RS232/422/485 ② Micro SD ⑥ CAN BUS ③ LAN/ PoE ⑦ 1 x USB 2.0 ④...

  • Page 10: E-Series Hmi 10.1

    E-Series HMI 10.1” Unit: mm Dimensions: 293.6 x 199.2 x 62.3 mm № Description № Description ① Mini USB Console (Linux use) ⑤ RS232/422/485 ② Micro SD ⑥ CAN BUS ③ LAN/ PoE ⑦ 1 x USB 2.0 ④ USB OTG ⑧...

  • Page 11: E-Series Hmi 15.6

    E-Series HMI 15.6” Unit: mm Dimensions: 421 x 260.6 x 65.5 mm № Description № Description ① Mini USB Console (Linux use) ⑤ RS232/422/485 ② Micro SD ⑥ CAN BUS ③ LAN/ PoE ⑦ 1 x USB 2.0 ④ USB OTG ⑧...

  • Page 12: Getting Started

    GETTING STARTED Turning On Your Device Follow the following steps to turn on your HMI device: 1. Connect a 3-pin terminal block to the HMI connector. 2. Connect the other side of the terminal block to the AC adapter. 3. Connect the AC adapter to the power cord. 4.

  • Page 13: Connecting To Other Devices

    Pin № RS-232 RS-422 RS-485 (Default) TxD- TxD+ RxD+ RxD- Serial port settings can be configured in Winmate application for Android OS. “Configuring Serial Port Refer to Settings” of this Quick Start Guide for more detail.

  • Page 14: Lan (Rj45) Connector

    LAN (RJ45) Connector The E-Series HMI supports one 10/100/1000 Mbps Ethernet interface for connecting to the internet. Pin № Signal Name Pin № Signal Name TX1+ TX1- TX2+ TX2- TX3+ TX3- TX4+ TX4- USB A Type Connector Use USB A Type (USB2.0) connector to connect your HMI device to other USB2.0 compatible devices.

  • Page 15: Can Bus Connector

    CAN Bus Connector Use CAN Bus connector for the HMI machine-to-machine communication. Signal Signal № № Name Name CAN_L CAN_H +5V/NC *PIN9 default is NC...

  • Page 16: Changing Serial Port Settings

    Changing Serial Port Settings Serial port can be configured for RS-232, RS-422 or RS-485. Winmate® provides serial port settings application for Android OS. To configure serial port settings follow the instructions below: Step 1 Settings > Accessibility Step 2 Accessibility > Comport-Setting...
  • Page 17 Step 3 Comport-Setting > Comport 1/ Comport 2/ Comport 3 * Select Comport 1/ Comport 2/ Comport 3 that you want to configure. Step 4 Comport 1 > RS232/RS422/RS485 * Configure Comport 1 settings...

  • Page 18: Ethernet

    Ethernet Main Menu Use Android application to connect Ethernet. Step 1 Connect Ethernet Cable to the HMI device. Step 2 Go to APPS. Open Ethernet application. Step 3 Ethernet APP main menu appears Setting Description Check Ethernet connection parameters: IP mode, IP Check Ethernet address, DNS address and others Enable Ethernet connection and configure its such as...

  • Page 19: Configuring Ethernet

    Configuring Ethernet Go to Apps > Ethernet > Configure Ethernet *Ethernet OFF is set by default. Swipe Ethernet ON to activate Ethernet connection. Connection Type Setting Description The device automatically capture IP-address from the DHCP (Default) router Allows to manually set up IP-address, DNS, Network and Static IP Gateway...

  • Page 20: Checking Ethernet Settings

    Checking Ethernet Settings Go to APPS > Ethernet > Check Ethernet Ethernet settings menu appears on the top right side of the desktop. For a more detailed Android 4.4 user guide, follow the download path below: http://static.googleusercontent.com/media/www.google.com/en/us/help/hc/images/android/a ndroid_ug_42/Android-Quick-Start-Guide.pdf...

  • Page 21: Winmate® Home Manager

    Winmate® Home Manager Winmate ® E-Series HMI comes with preinstalled APP named Winmate® Home Manager (WHM) which let the device manager to lock the launcher then the user can only use one application assigned by the device manager. How to Lock Applications Step 1 In the main APPS window, select the Home Manager APP tap it to open.
  • Page 22 Step 2 Go to “Application Selector”, and choose the app which you want to run up automatically after booting. Step 3 Go back to “Home Selector” and press “Clear and Reset Default Home”.

  • Page 23: How To Reset Whm

    Step 4 Select “Restrict Home” and “Always”, and then restart the computer to enable these settings. The system will automatically start the application which you selected and lock Whatever you press home key or back key; the system will go back to the same application which you have selected.

  • Page 24: Turning Off Your Device

    Step 2 System will request the password to login. Default password is “0000”. Step 3 Restart the system and you will go back to the normal Launcher. Turning Off Your Device Disconnect the power cord from the HMI device to completely turn off the device.

  • Page 25: Installation

    INSTALLATION Wiring Requirements The following common safety precautions should be observed before installing any electronic device:  Strive to use separate, non-intersecting paths to route power and networking wires. If power wiring and device wiring paths must cross make sure the wires are perpendicular at the intersection point. ...

  • Page 26: Mounting Solution

    Mounting Solution VESA Mounting VESA Mount is a widely used mounting solution suitable for all kinds of industrial applications. Notice that VESA Mounting solution applies only to 7” E-Series HMI. Dimensions Screw Hole Diameter 75 x 75 mm VESA M4 x 3 mm *With customer’s bracket Mounting Steps: 1.

  • Page 27: Panel Mounting

    Panel Mounting In addition to elegant design, panel mount solution is making the HMI unit easy to clean and maintain. The HMI device is secured to the fixture from the rear by using the mounting brackets included in the package. Cutout dimension ( W x D in mm) 7”...

  • Page 28: Specifications

    SPECIFICATIONS Hardware Specifications Model Name W07FA3S-EHT1 W10FA3S-EHH2 W15FA3S-EHA2 Display 7” TFT 10.1” TFT Size/ Type 15.6" TFT Resolution 1024x600 1280 x 800 1366 x 768 Brightness 320cd/m (typ.) 350 cd/m (typ.) 400 cd/m (typ.) Contrast Ratio 500 : 1 (typ.) 800:1 (typ.)

  • Page 29: Appendix

    APPENDIX Appendix A: Cleaning the Monitor Before cleaning:  Make sure the device is turned off.  Disconnect the power cable from any AC outlet. When cleaning:  Never spray or pour any liquid directly on the screen or case. ...

  • Page 30: Appendix B: Winmate Software Development Kit

    Appendix B: Winmate Software Development Kit Winmate® provides Software Development Kit (SDK). The table below lists SDK provided by Winmate for E-Series HMI with Freescale® Cortex® A9 i.MX6 Dual Core processor: Item Driver Description Android Driver USB Driver Android Driver...
  • Page 31 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...

This manual is also suitable for:

W15fa3s-eha2W10fa3s-ehh2
