Information Windows
Information windows can be changed with
main window showing the solar system diagram.
INFORMATION
E.TODAY 10.7kWh
E.YESTERDAY
E.TOTAL 0000753kWh
ΔT12 8.5K
ΔT34 3.5K
E.BOILER 000022kWh
COMPIT
SolarComp 951 ver 4.0
Menu Structure
When
following menu:
MENU
A. OPERATION MODE
B. USER SETTINGS
C. CLOCK SETTINGS
D. SERVICE SETTINGS
E. MANUAL MODE
F. JĘZYK/LANG./SPRACHE
S C 951 model u7.x, Rev. 1
OLAR OMP
Main information window. It shows the system diagram,
sensor location and measured temperatures. In the top right-
hand corner, instantaneous power output obtained from the
solar panel is displayed. In variant no. 4 below the collector's
power output CH boiler power output is displayed. At the
bottom of the display the information bar provides information
on the current operation mode as well as the symbol of the
current day and time.
Weekly power chart; it shows daily energy obtained from the
solar panel within the last 7 days.
Daily instantaneous energy chart; it shows changes in the
energy obtained from the solar panel from 6:00 to 20:00.
E.TODAY – solar energy obtained the current day.
E.YESTERDAY – energy obtained the previous day.
12.2kWh
E.TOTAL – solar energy meter from the date of system
commissioning.
P1: 90%
ΔT12 - T1-T2 temperature difference.
P1: 90% - information on P1 pump output.
ΔT34 - T3-T4 temperature difference (variant no. 6).
E.BOILER – meter of energy obtained from the CH boiler
(variant no. 10).
Controller's name.
Software version.
is pressed in the main window mode, the controller will display the
Use
and then press
return to the main window.
and
and buttons to highlight the desired option
to access the next level. Press
buttons beginning from the
to
