Variant no. 5
Tank loaded from the solar panel – system with three sensors.
•
Circulation pump control.
•
Heat transfer to auxiliary tank (based on temperature difference).
•
Tank loading
The loading of the tank is described on page 20.
Heat transfer
Heat transfer depends on T3-T4 temperature difference and temperature T4.
The set temperature of tank no. 2 is determined by parameter B.02 DHW TANK 2 SET
TEMPERATURE. Hysteresis for the set temperature is 2K.
Parameter D.10 T3-T4 DELTA FOR P2 PUMP ON determines T3-T4 delta for
activating P2 pump.
Parameter D.11 T3-T4 DELTA FOR P2 PUMP OFF determines T3-T4 delta for
stopping P2 pump.
Holiday mode does not affect heat transfer.
DHW circulation
DHW circulation is described on page 19.
S C 951 model u7.x, Rev. 1
OLAR OMP
T1
P2
P1
P3
T3
T2
T4
