- Page 1 SOLARCOMP 911 CONTROLLER FOR SOLAR COLLECTORS Installation and Operating Instructions for model u6.x, Rev. 2, May 2011...
-
Page 2: Safety Instructions
By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health. Penalties may be applicable for incorrect storage or disposal of this waste, in accordance with national le gislation. SOLARCOMP 911 model u6.x, Rev. 2... -
Page 3: List Of System Operation Variants
Introduction SOLARCOMP 911 controller has been designed for control of thermal solar heating systems. Basic features of the controller include: 1. Special purpose graphic display – a special-purpose display makes the operation of the controller easy. It helps to identify the system variant used and system parameters. - Page 4 Variant no. 4 – tank loaded from the solar panel plus extra heat discharge. Variant no. 5 – tank loaded from the solar panel plus heat transfer to another tank (based on temperature difference). SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2...
-
Page 5: Control Panel Description
• in editing mode – press to increase parameter value. 5. Minus / down arrow button • press to scroll down the parameter list , • in editing mode – press to reduce parameter value. SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2... -
Page 6: Lcd Display Description
Fig. 2 presents LCD display with all the symbols displayed. During standard operation only the required symbols display. 1. SOLARCOMP 911 controller - 1 pc. 2. T1301 collector sensor (T1) - 1 pc. 3. T1001 tank sensor (T2) - 1 pcs. -
Page 7: Sensor Connections
Sensor connections Controller Operation SOLARCOMP 911 works with four sensors: Basic Parameter Readings When the controller is on, the display shows the current system variant and measured • T1301 collector T1 sensor. It can be connected to the controller with a max. 30 m panel temperature. -
Page 8: Basic Parameter Settings
230 V~ 50Hz +5/-10% 11, 12 - vacant 13, 14 - P2 pump output or heating coil contactor control 15, 16 - P1 loading pump input SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2... -
Page 9: Controller Installation And Commissioning
If T1-T2 difference drops below this value, the tank loading pump will switch off. Enabling of a sound alarm. 0 – sound alarm disabled, 1 – sound alarm enabled. Fig. 10 SOLARCOMP 911- pictoral view SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2... - Page 10 If T1-T2 difference drops below this value, the tank loading pump will Controller software version. A read only parameter. switch off. Enabling of a sound alarm. 0 – sound alarm disabled, 1 – sound alarm enabled. SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2...
-
Page 11: Service Parameters
T1 sensor calibration (Setting range -9,9 to 9,9°C, step 0.1°C, default Enabling of a sound alarm. setting: 0°C). 0 – sound alarm disabled, 1 – sound alarm enabled. SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2... -
Page 12: User Parameters
If this temperature is exceeded by the tank (T3), heat discharge is started. Enabling of a sound alarm. 0 – sound alarm disabled, 1 – sound alarm enabled. SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2... -
Page 13: Advanced Parameter Settings
MWh and kWh MWh – megawatt-hour meter meters. Parameter access code. To edit user parameters select code 99. To go to manual mode select code 105. SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2... -
Page 14: Manual Mode
In the case of a sensor failure, check temperature readings. If the sensor is damaged, a relevant temperature reading will be replaced by „Err”. Check if the sensor is connected appropriately or replace the sensor. SOLARCOMP 911 model u6.x, Rev. 2 SOLARCOMP 911Operating Instructions model u6.x, Rev. 2...
