D. SERVICE SETTINGS
14.DEFROSTING TIME
120s
MIN 0 MAX 600
D. SERVICE SETTINGS
15.HEAT CONVECTION
DETECTION
NO
D. SERVICE SETTINGS
16.SERPENTINE PANEL
(periodic operation)
0s
FUNCTION
DISABLED!
MIN 0 MAX 195
D. SERVICE SETTINGS
17. ANTI-FREEZE
FUNCTION
10.0°C
FUNCTION
DISABLED!
MIN -35.0 MAX 10.0
D. SERVICE SETTINGS
18. ANTI-LEGIONELLA
FUNCTION
0°C
FUNCTION
DISABLED!
MIN 0
D. SERVICE SETTINGS
19.HEAT METER TYPE
1
MIN 1
16
Solar pump operation time after starting panel defrosting
mode.
Default setting: 120s
Activating the detection of gravity heat convection from the
tank.
Default setting: NO.
Serpentine collector function.
By analysing panel temperature changes the controller
periodically activates the solar pump for the time set in this
parameter. It can measure the instantaneous temperature of
the panel and activate tank heating or panel overheating
protection function.
Default setting: 0s = function disabled.
Function protecting the solar panel from freezing. This
parameter determines the panel temperature below which the
solar pump is activated in order to protect the solar thermal
fluid from freezing or thickening. If tank temperature drops
below 4°C, the controller will switch off the anti-freeze
function. Selecting 10.0°C disables the function.
Default setting: 10°C = function disabled
ANTI-LEGIONELLA function involves periodic sterilization of
the tank. This parameter determines the set tank temperature
when this function is enabled. Sterilization starts weekly on
Monday at 11:00 a.m. It stops when the temperature reaches
the value set in this parameter.
MAX 80
Default setting: 0°C = function disabled
HEAT METER TYPE
1 – primary meter,
2 – high precision meter – requires T4 sensor to be placed on
the return from the solar tank coil pipe. Operates in variants
nos. 1..4.
MAX 4
3 – primary meter with a flow meter pulser connected to
terminals 9,10. Operates in variants nos. 1..9.
4 – high precision meter (with T4 sensor) with a flow meter
pulser connected to terminals 9,10. Operates in variants nos.
1..9.
Default setting: 1
S C 951 model u7.x, Rev. 1
